Uses a trimming knife blade which is contained in a movable slide. Adjustment is via a thumb wheel. Its accurately adjustable and works pretty well, I like it more than a traditional scraper. Suitable for Faux bindings and normal bindings.
Sundries Required
- M4 threaded rod – 72mm
- M4 Nut x 3
- M4 Thumb Wheel – example https://www.amazon.co.uk/sourcing-map-Knurled-Threaded-Plating/dp/B07L68ZZ31/
Printing in PLA or PETG is fine, I have found slight under extrude (97%) to work nicely. I’ve included a step file of the blade carrier so it can be adjusted to fit different thumbwheels.
There is a printable thumbwheel included but it needs a bit of care to print and is not as good as a machined one.
