Beta RR Ignition Switch mount
Obliczymy ostateczną cenę na podstawie wybranego pliku. Sprawdzisz ją i zaakceptujesz przed płatnością.
Zapisane na tym urządzeniu.
Informacje o modelu
- Źródło
- Printables
- Kategoria
- Automotive
- Licencja
- Creative Commons — Attribution — Noncommercial — Share Alike
Since Beta’s competition enduro bikes don’t come with an ignition switch by default, riders are usually forced to rely on steering locks or other external solutions.
To improve security, I designed this ignition switch mount to install a standard key switch.
In my setup:
- The key switch interrupts the start button
- The kill switch is held permanently active when the ignition is off
This prevents starting the bike without a key.
This is a custom mount for installing an ignition switch on a Beta RR 390 4T (2022).
May also fit other Beta 4T enduro models (e.g. 350, 430, 480) from other build years. Check dimensions before printing.
I printed mine in ABS to handle heat from the headlight and direct sunlight.
The mount is installed using the right front indicator (blinker) screw.
Designed to fit this ignition switch from Amazon:
https://www.amazon.de/dp/B09K486WRV?ref=ppx_yo2ov_dt_b_fed_asin_title&th=1
This is a hobby project. I take no responsibility for damage, improper use, or any issues that may result from installing or using this part. Use at your own risk.
