The original page has become flooded with over 60 files. It is a pain to update both imperial and metric versions, especially since I only use a select few for my personal build. This is what I use to hit 230 fps consistently using the same PT volume as a standard Zinc.
Since this is my own build, the BOM is even wider and more annoying. Thrust bearing and metal PT is not needed, but helps when trying to push it a little bit further. The thrust bearing deals with the issue of line rotation.
Most parts should be compatible with other versions. I recommend the new turnaround and barrel.
Notable changes:
Updated Turnaround and BarrelShroud
0.509" aluminum barrel
MidLock variant
Less support generated/needed
Holes for iron sight dots using cut filament.
New Plunger
Uses a modified version of the AKBM plunger body and head design.
Thinner O-ring, less friction. 3-5+ second air seals.
BOM:
https://docs.google.com/spreadsheets/d/1y0SEFztV5ueGZxX_imNLSp0Nt9n9m-7Pvh4JfKasnm8/edit?usp=sharing
check the links and make sure they are correct.
