This is a surround sound speaker system I've been working on for a while. For now this is just to show the parts of the speaker enclosure. When I get one assembled I'll post some pictures
This uses 4 small 16 ohm Samsung speakers from Parts Express that were less than $2 at the time I got them. They will be wired in parallel for 4 ohms. The tweeter is a 4 ohm Dayton Audio tweeter.
I've designed this so anyone could take it and reconfigure the front baffle with some 3D modeling software to make different speakers. For instance a single full range speaker or a more conventional 2-way. The box can also be resized to fit a particular speaker for good sound. This particular configuration is 9.5 inches tall, 5.2 inches wide and 4 inches deep.
The box is actually a remix of https://www.thingiverse.com/thing:1847185
Ok, here are some of the parts from Parts Express:
Terminal Cup: Round Speaker Wire Terminal Cup Spring Type Part # 260-294
Speaker: Samsung BN83-01803A Full Range Speaker 16 ohm Part # 289-2168
Tweeter: Dayton Audio TD20F-4, 3/4" soft dome 4 ohm tweeter Part # 275-020
