BitBeam EggBot

This is BitBeam version of ball plotter, knows as EggBot. Print is still in progress now.

Printed files

• 1 x bb-adp-ball-30.stl
• 1 x bb-adp-ball-40.stl
• 1 x bb-adp-shaft-8.stl
• 2 x bb-adp-stp-5x3-th.stl
• 2 x bb-a90-2x4.stl
• 1 x bb-a90-2x5.stl
• 3 x bb-a90-3x4.stl
• 1 x bb-a90-3x5.stl
• 1 x bb-a90-3x6.stl
• 2 x bb-a90-4x4.stl
• 2 x bb-a90-4x5.stl
• 1 x bb-b-12x2-cn.stl
• 1 x bb-b-20x2.stl
• 1 x bb-b-20x2-logo.stl
• 2 x bb-bearing-608.stl
• 2 x bb-mot-28BYJ-frame.stl
• 1 x bb-pencil.stl
• 1 x bb-srv-small-m.stl

Support material

• 4 x screw M3x12 for electronic
• 4 x screw M3x8 for motor adapters
• 8 x nut M3
• 4 x washer_M3x3.stl
• 4 x screw M4x10
• 2 x screw M4x15
• 30 x screw M4x20
• 6 x screw M4x30
• 3 x screw M4x35
• 1 x screw M4x40
• 2 x screw for wood 2mm (for micro servo)
• 47 x nut M4
• 1 x 10x70mm spring

Motors and Other

• 2 x 28BYJ stepper motor
• 1 x 9G Micro Servero
• 1 x bearing 608

Electronic

BBC Micro:bit kitronic version

• 1 x bb-drv-mbkitronic.stl
• 1 x Kitronic BBC Micro:bit motor driver
• 2 x stepper drivers or another way
• 1 x BBC Micro:bit

BBC Micro:bit kittenBot version

• 1 x Not yet, I'm waiting for Robotbit
• 1 x KittenBot Robotbit
• 1 x BBC Micro:bit

ESP32 version

• 1 x bb-rb-octopus-9x11.stl
• 1 x OctopusLab Robot Board with Drivers
• 1 x ESP32

Arduino Version

• 1 x bb-drv-mbkitronic.stl
• 1 x CNC Shield + Drivers
• 1 x Arduino UNO

For more information see https://bitbeam.cc
