Belt path optimized version of the EVA mount for Ben Levi's BLV Cube.
- Ocena
- 5 / 5
- Polubienia
- 18
- Pobrania
- 89
- Wydruki
- 1
- Wyświetlenia
- 1255
- Oceny
- 1
Aktualizacja u źródła:
Informacje o modelu
- Źródło
- Printables
- Kategoria
- Other Printer Parts & Upgrades
- Licencja
- Creative Commons — Public Domain
Initially adapted this version when EVA first was released by the RatRig team.
Design goals were to:
- Make EVA 3.0 work with Ben Levi's BLV mgn cube
- Minimize changes to EVA3.0 to maximize compatibility with EVA components
- Ensure that the belt path placement was adopted from EVA (use of the belt grabbers), but optimize for BLV's 6mm belts and belt path
BLV cube - https://www.blvprojects.com/blv-mgn-cube-3d-printer
EVA 3.0 carriage - https://main.eva-3d.page/
At the time of design, there were no other adaptations for EVA3.0 and the BLV cube, so I made my own. Since the EVA3.0 release, there are now a number of other amazing adaptations by other makes. I decided to release this version anyways, because I feel that there is a significant enough difference in how the front-facing belt paths work.
I have a top-mount that is attached to a cable chain. This is not part of EVA, but I've included it in case someone finds it useful.
There is a standard version without the cable chain protrusion.
Note: if you are using this mod, the front facing belts actually need to cross over behind the front mount. They attach on the opposite side of the front plate than normal. This means, you will need belts which approximately an additional 6cm longer than stock BLV.
