Raspberry Pi Zero 2W Snapfit Casing Aircooled
Obliczymy ostateczną cenę na podstawie wybranego pliku. Sprawdzisz ją i zaakceptujesz przed płatnością.
Zapisane na tym urządzeniu.
Informacje o modelu
- Źródło
- Printables
- Kategoria
- Computers
- Licencja
- Creative Commons — Attribution — Noncommercial — Share Alike
When the printer and the camera asks more of your Raspberry Pi and its temperature rises, you'll have to cool it down to prevent throttling.
So if you got a spare 2510 fan laying around like me, you can use it for cooling your Raspberry. Or you can pick one up from your favorite (online) supplier and choose your voltage (5, 12 or 24V), so you can power it by the Raspberry Pi (5V) or the printer's/external power supply.
Printing Material: PLA, PETG, ABS, ASA
40% or less infill
just print it as it is or don't use top and bottom layers to get a mesh
You'll need:
- 2510 fan (I've used a Winsinn 5V fan)
- Du Pont connector (when using the Raspberry as a power supply)
- Inserts: M2x3,5x3
- Bolts: M2x12
Enjoy!
Update: Just tested the model. 15°C temperature decrease on my RPi Zero 2W with no heat sink installed.
