Made a remix from Gehäuse für IR Lesekopf Hichi IR TTL & D1 Mini mit Ringmagnet by timmmmme - Thingiverse to fit the case for a ESP32 Wemos D1 mini and made it round so it fits several power meters. Fits a Neodym Ringmagnet 27 x 5 mm 16…
Script for eBZ DD3 2R10 ODZ1 >D >B ; https://tasmota.github.io/docs/Smart-Meter-Interface/#ebz-dd3-obissml ; OD-type: 7 data bits, even parity, one stop bit, 9600 baud (9600 7E1) - OBIS ASCI protocol SerialConfig 7E1 TelePeriod 10…
Halterung um ein Marstek CT003 Smartmeter an einem eBZ Stromzähler zu befestigen
Halterung um ein everHome EcoTracker IR Smartmeter an einem eBZ Stromzähler zu befestigen. Inklusive seitlicher Verdrehsicherung an der das Smartmeter zusätzlich mit doppelseitigem Klebeband fixiert werden kann
This is a case for LoRaSmartMeter, my SML electricity meter LoRa Adapter. Its designed to fit on a EasyMeter Q3A or eBZ DD2. All other information you could find in my GitHub Repo foorschtbar/LoRaSmartMeter . Additional Parts 1x Micro USB…
Smartmeter infrared read/write sensor case for various smart energy meters used in germany. Parts list: Threaded inserts and M3 screws (2pcs) 5mm Neodymium Magnets (6pcs)
I created a case specific case to combine the Hichi IR V1.1 IR read/write interface and Wemos D1 Mini to report the power meter readings via MQTT to ioBroker. Just follow the instructions within the linked YouTube videos: ttl ir lesekopf…
Housing for ESP32 Wroom plus MicroE M-Bus Slave Board. Reads all the relevant values from Smartmeter Kaifa MA309M with ESPHome Software from DomiStyle and integrates it into Homeassistant/MQTT.
Read the data from a smartmeter with the Hichi IR TTL reading head and a WEMOS D1 Mini and display it in the browser. You can also process the data further with ioBroker.
Dies ist ein spezielles Gehäuse, welches einen ESP mit aufgestecktem IR-Interface aufnimmt. Der mit Tasmota bespielte ESP übermittelt die Zählerstände im Heimnetzwerk. Das Gehäuse hält mittels Magnet am Stromzähler, welcher im unteren…
I designed this case to attach the Flussmittelschorsch24 sensor board to my Landis Gyr+ E220 energy meter. I usually stick the magnets into my cases. But in this case I just fixed the magnets with adhesive tape. PCB: https://fms.lol…
This 3D model is an adapter housing designed for the board of the bitShake SmartMeterReader availible on Amazon https://www.amazon.de/dp/B0CCMXSPVX , now integrated with Home Assistant using pre-flashed Tasmota firmware for enhanced…
As I needed readout heads for three smartmeters, which are connected to one ESP32, I've designed this head with a screwable cover and a strain relief (printed in TPU). I'm using https://www.ebay.de/itm/285350331996 as PCB for IR LEDs).…
