Backup Camera Dash Mount
Order a print of this model
We calculate the final price from your selected file. You review and accept it before payment.
Saved on this device.
Model information
- Source
- Printables
- Category
- Automotive
- License
- Creative Commons — Public Domain
Dodge Ram1500 Backup Camera Mount
- Year: 2015 Dodge Ram1500 (May fit other model years)
Adapted to utilize existing holes for dash board coin area.
Compatible for Type-S after market rear camera LCD, utilizing Bluetooth license plate camera.
Additional model includes the coin mat as a dress inlay.
Could be modified as a cell / mobile phone holder if desired.
- Material: ABS
- Infill: 30%
- Bed Temp: 110c
- Nozzle Temp: 225c
- Infill Type: Adaptive Cubic
- For added structural support & printed
- Position Optimized for Print Time and Strength.
- Positioned for minimal supports & so stress is not in line with layer lines when LCD is slide into place.
- Utilized Paint-On Supports
- Used “SNUG” support settings to minimize support and ease of release.
