Building Brick STL Generator
Parametric generator optimized for FDM 3D printing (compatible with common bricks).
Recommended PETG Settings
For fast results with PETG, use these PrusaSlicer settings:
Setting | Value |
|---|---|
Profile | 0.2mm SPEED |
Infill | 10% Adaptive Cubic |
Nozzle Temp | 235°C (240°C first layer) |
Bed Temp | 85°C |
Fan | 30-50% (off for first 3 layers) |
Retraction | 0.8mm @ 35mm/s |
Perimeters | 2+ |
A pre-configured PrusaSlicer profile is included at slicer-profiles/petg-speed-mk3s.ini.
Print Time Estimates
Generate a table of estimated print times for various MK3S-compatible sizes:
Using the included slicer settings
╔═══════════════════════════════════════════════════╗
║ PRINT TIME ESTIMATES - 600% Scale, PETG, MK3S ║
╚═══════════════════════════════════════════════════╝BRICKS
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Part Time Filament
───────────────────────────────────────
1x1 1h 59m 34g
1x2 3h 2m 64g
1x3 4h 14m 92g
1x4 5h 34m 123g
2x2 5h 26m 115g
2x3 7h 38m 164g
2x4 10h 3m 217g
4x4 19h 7m 411g
PLATES
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Part Time Filament
───────────────────────────────────────
1x1 1h 5m 17g
1x2 1h 47m 33g
1x3 2h 29m 48g
1x4 3h 16m 63g
2x2 3h 22m 62g
2x3 4h 55m 92g
2x4 6h 29m 121g
4x4 12h 54m 238g
TILES
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Part Time Filament
───────────────────────────────────────
1x1 51m 15g
1x2 1h 32m 28g
1x4 2h 50m 55g
2x2 3h 0m 54g
2x3 4h 20m 80g
2x4 5h 44m 105g
