GBA SP(ocket)
We calculate the final price from your selected file. You review and accept it before payment.
Saved on this device.
FDM friendly STL files to make a hingeless GBA SP.
- Rating
- 0 / 5
- Likes
- 16
- Downloads
- 81
- Makes
- 0
- Views
- 606
- Reviews
- 0
Updated at source:
Model information
- Source
- Printables
- Category
- Video Games
- License
- Creative Commons — Attribution — Noncommercial — Share Alike
A FDM-friendly hingeless shell for a GBA SP (AGS-001 or AGS-101). Utilizes original GBA (AGB-001) D-pad, AB buttons and power LED lightpipe. Re-uses original GBA SP screws and start/select buttons, and all button membranes. Requires some light soldering to relocate the speaker, and some glue for the button plates. It removes the brightness button, so I'd recommend a drop-in replacement screen with touch sensors if you want adjustability.
Files included:
Face Plate
Rear Screen Plate
D-pad Socket
AB Socket
Start&Select Socket
Start&Select Spacer (print x2)
Speaker Cover
Heavily inspired by Xipher Design's Slab.
Originally posted on my Ko-Fi.
