Dragonball Z Vegeta Scouter

I remixed this model from https://www.thingiverse.com/thing:2272830 by https://www.thingiverse.com/Cronos-FDM

• The first few renders have additional detail not captured in the 3D models
  • The PCB is more simple than the renders
  • The words on the display do not print
• The speaker grill was changed by the author as the tiny holes did not print well

Notes:

• When I sliced the PCB in Orca Slicer the speaker grill mounting holes were incomplete. I was still able to attach it as the nuts covered enough to clamp it down.

• I painted the PCB a textured silver, but I would have printed it in a bronze filament if I had it available.

• My modeling skills are nearly non-existent and this was accomplished through trial and error in Fusion.

• I was unhappy with the multi-piece design of the original and decided to combine the cover and the display arm together.

• I also changed the display arm to be more accurate to the show. Removing the arrows and remaking the button.

• I changed the button to allow it to be printed separately as well so I could make it in red.

Printing:

• PLA for all pieces is fine. PETG was used for the display and the button as it is what I had on hand.

• Infill: I did 15% for all pieces except the button and display can be printed higher. I would print the button at 50% or higher to make the pegs more durable. I also printed the button at 50% speed for my printer. (Flashforge Adventurer 5m)

• Supports are needed for the following parts.
  • Scouter_Body
    • Print with the ear piece hook up and off of the bed
    • I was unable to print this piece with the ear piece hook on the bed
  • Scouter_Display_Arm_Cover_Combo_Improved
    • I painted supports myself, but you only need them on the bottom edges and bottoms of screw holes (auto generated should work fine)

• The parts are all oriented as they should be printed within the plated files.
• Please use the plated files to print or at least look at them to see the proper orientation.


• I print on a Flashforge Adventurer 5m with a .4 nozzle
  • PLA
    • 220 C nozzle
    • 55 C Bed

  • PETG
    • 260 C nozzle
    • 70 C Bed


Materials for assembly:

• 3d Printed Parts
• 4x Countersunk M3 x 12
• 4x Round Cap M3 x 16
• 4x M3 nuts

Assembly Instructions:

1. Use the M3 x 12 screws to attach the speaker grill to the scouter body.
2. Attach the PCB to the opposite side of the scouter body on the M3 x 12 screws using the M3 nuts.
3. Attach the Scouter cover and display arm combo to the Scouter body over the PCB using the M3 x 16 screws. Go slow to make sure you don't strip the plastic in the body.
4. The speaker pad, button, and display can all be push fit together.
