These inserts attach to their neighbors using 3x2mm magnets preventing them from rattling around. Easily extract components from the stored reel by pushing down on the components and moving your finger backwards. The design was made using…
Print approx. €0.52–€0.64 excl. taxPreliminary estimate for one variant
Instructions I'll add some more versions (and better images) of this later as I fill up my cases and see what my need will be, but you can always grab the Rhino .3dm file and modify it yourself :) Update: turns out 3 compartments only…
I've made a recent update, changing how the slot works. The previous version with an angled entry from the top left little space for a label, and they were difficult to remove due to stairstepping on the ramp. The parametric Fusion source…
Fits nicely to organise small parts. I used many for both small screws and electronic components. The inside of the insert is "rounded" to make it easy to pickup parts.
My first ever creation. I created these because my cabinet was missing two drawer units, and these fit perfectly with a functional lip to prevent them from sliding out too far or falling through. Technical Specifications: Height: 37mm…
Description These clips can easily be fitted over the latches on Raaco "Service Case" and "Assorter" cases to prevent them from opening when your suitcase is being thrown around by airport luggage handlers. They simply clip on, so they…
These will be stackable and still fit perfect in Raaco Carry Lite 55+80. If you have a 55, then you need a total of 2 high. So either 2x1High or 1x2High. For 80 you need a total of 3 high. Print with no supports. As of now, I only need…
I modified the original, so that the thin parts that goes into the wall/board does not break as easily. This is the M5 version I recommend you print in the orientation shown, so that it improves the strength of the weakest points even…
The raaco metal storage cabinet comes I bought came with 44 bins and a few dividers. I needed more dividers and found the model by jdpp44 on Thingiverse. The original bin dividers had an up marking for easy/even easier installation; the…
Mit diesem Doppelfach lassen sich größere Teil in einem Raaco 1248 Magazin unterbringen. Es gibt zwar in der Mitte eine kleinen Steg, der bei vielen Teilen aber nicht stören sollte. Drucken, Print: no support, print small walls, wall line…
A rack for flat tools like files, chisels or scrapers that sits nicely onto the Raaco tool wall panels. There is a version with 4 slots and a version with 2 wider slots. I have found the one with 2 slots the most usefull so far. Can be…
Simple hooks that you can lock in place with a 3x10 mm screw. First number in the names is the lenght, and the second number is the hight of the hook part. Both are inside measurements. Print instructions Print with PETG - 4 perimeters…
Snaps on to the Snap Tool Rack System Grid of 5x3 Works great with Raaco bins but also https://www.printables.com/model/479356-raaco-compatible-sorting-boxes-mega-pack/collections Mouse ears is for when your slicer does not have this brim…
Raaco Sortierkisten Halter. Modularer Aufbau, Stützstruktur nur für die verdeckten Verbinder benötigt. Gedruckt mit Petg. Der Abstand der Wände, an die die Halter geschraubt werden, muss 357mm betragen.
This is a M3 bolt sorter and container for the Raaco assorter 55 boxes. The model consists of 2 parts: the bottom organizer bin, and the top sorter. The bin is designed to fit in 2x3 modules of the assorter 55 container, and allows the…
A storage cup for pencils and what not, that sits nicely onto the Raaco tool wall panels. The cup has 4 compartments to ensure stuff stays organized. Can be locked place in using a 3x10 mm screw. Print instructions To print this you need…
A plier rack that sits nicely onto the Raaco tool wall panels. Can be locked place in using a 3x10 mm screw. Print instructions To print this you need 3 parts. 2x Single Universal Clip 1x Pliers Rack x4 Print with PETG - 4-5 perimeters…
A Raaco-grid compatible tray to hold a stanley 6-pc punch kit: https://www.stanleytools.com/product/16-226/6-pc-punch-kit?tid=576431
This model provides a fully parametric SCAD design for creating a drawer grid inlay that allows you to reuse the inserts from Raaco Assorter 55 boxes in a drawer setup. By leveraging this design, you can repurpose your Raaco inserts…
Feet for the popular and affordable Raaco 126762 C11-44 small component storage cabinet. If, like me, you don't wall-mount your cabinet, these feet printed in a flexible filament like TPU will help stop them from damaging surfaces.
Various insert trays for the Raaco storage system. Additional models will be added in the future. Feel free to leave some suggestions! NOTE: I do not reccoment vase mode. The walls are too thin in my experience. 2025 june 7: Added S Raaco…
raaco 6 slot insert for assortment cabinet. I designed this insert to efficiently store resistors. One insert can store 6 different values of resistors; and one medium box in the raaco assortment cabinet can store two inserts. Size Insert…
raaco 2 slot longitude insert for assortment cabinet. One insert has 2 slots and one medium box in the raaco assortment cabinet can store two inserts. Size Insert box size Width: 80 mm. Depth: 130 mm. Height: 25.9 mm. Slot size Width:…
raaco 2 slot offset wall insert for assortment cabinet. One insert has 2 slots and one medium box in the raaco assortment cabinet can store two inserts. The separation wall is offset 1/3. Size Insert box size Width: 80 mm. Depth: 130 mm.…
raaco 2 slot insert for assortment cabinet. One insert has 2 slots and one medium box in the raaco assortment cabinet can store two inserts. Size Insert box size Width: 80 mm. Depth: 130 mm. Height: 25.9 mm. Slot size Width: 77.6 mm.…
raaco 3 slot insert for assortment cabinet. One insert has 3 slots and one medium box in the raaco assortment cabinet can fit two inserts. Size Insert box size Width: 80 mm. Depth: 130 mm. Height: 25.9 mm. Slot size Width: 77.6 mm. Depth:…
raaco 4 slot cross insert for assortment cabinet. One insert has 4 slots and one medium box in the raaco assortment cabinet can store two inserts. Size Insert box size Width: 80 mm. Depth: 130 mm. Height: 25.9 mm. Slot size Width: 38.2…
raaco 1 slot insert for assortment cabinet. One insert has 1 slot and one medium box in the raaco assortment cabinet can store two inserts. Size Insert box size Width: 80 mm. Depth: 130 mm. Height: 25.9 mm. Slot size Width: 77.6 mm.…
This is a shelf holder designed for the Raaco Assorter 6-x. I have a few of the Raaco Assorter 6 units and needed a holder for them, so I created this rack. The rack consists of three parts: a left side, a right side, and a spacer to…
Simple divider for Raaco 150-00 ("small") drawers. Made with SolveSpace.
Inserts for some Raaco assorter boxes. All inserts have a tab to make it easier to lift the insert out of the assortment box. All insert boxes have a shelf where a 12 mm sticker fits nicely. The insert boxes are relatively sturdy and have…
Designed new Raaco drawers to replace broken drawers. Two of these drawers replaces the old drawer. Raaco uses many different sizes, check measurements before printing. Length: 140 mm (+handle) Width: 70mm Height: 60mm (+extra drawer…
Size A6, 157 mm x 109.25 mm, Height 1/3, 14.9 mm Size A6, 157 mm x 109.25 mm, Height 1/2, 22.35 mm
A quick remix to add 2 versions of a 55x(0.5x2)x1 container. Single 55x1x1 container split into 2 0.5 rooms. Both a horizontal and vertical version.
Generated with https://gridfinity.perplexinglabs.com/pr/grips/0/0 Included are some half-sized bins, generated with https://gridfinity.perplexinglabs.com/pr/gridfinity-extended/0/0 - 0,5x 1 - 1,5 x 1 - 1,5 x 2
3 different insert-layouts - two fit in one assorter-box to keep your stuff organized. Assorter Box Dimensions of Assorter Box 261 x 338 x 78 mm Assorter Box "80 4x8-0“ (136235.0) at Amazon: https://amzn.to/4nXbaET INSERTS (2 fit in…
4 different insert-layouts - two fit in one assorter-box to keep your stuff organized. This is the 55-Version of the Height 80 Raaco Assorter inserts. Assorter Box Dimensions of Assorter Box 261 x 338 x 55 mm Assorter Box "55 4x8-0“…
Separator walls for drawers in the Clas Ohlson / Raaco parts cabinet / organizer cabinet, part no 31-2376, 31-2375 and others. Parametric, your own choice of colour and far cheaper than getting them from Clas Ohlson (currently about €5.50…
I've made a recent update, changing how the slot works. The previous version with an angled entry from the top left little space for a label, and they were difficult to remove due to stairstepping on the ramp. The parametric Fusion source…
Insert for Raaco 150 System organizers like the CarryLite 150, has angled buttom for the ability to stack. Should print alright without any support in PETG, perhaps add more perimeters for better results. You can use the VarSet parameters…
Printed in PLA. Fits well and mixes well with original inserts.
title says it all....i guess. Fits 6er high gridfinityboxes
Some bins i made, they fit well and have a rounded bottom for getting small parts out, and a lip at the top for labels I'll add more to these as i make new ones.
Fits nicely to organise small parts. I used many for both small screws and electronic components. The inside of the insert is "rounded" to make it easy to pickup parts.
Recently I bought some Raaco storage drawers for cheap. While organizing my stuff in them I realized that the amount of drawer dividers that came with the drawers was insufficient. While buying additional dividers is quite cheap, I didn't…
I have a number of Raaco C11-44 storage cabinets but find that the type 150-00 drawers are often too small. So I made these drawers that fit 1-4 slots in the cabinets (5 is too wide for my printer). The grooves in the bottom sit over the…
Made some nameplates to label the drawers in my Raaco 126762 44 compartment organizer and thought they may be useful for others. Have included all the nameplates I used as STEP files but also the Solidworks parts so you can make your own…
Wanted to put some screwdrivers/pliers into my Raaco 126762 organizer but had already used up the full width drawer at the bottom and the 1/3rd width drawers were too small. Designed this one to replace two of the 1/3rd width drawers as…
A half height version of ArnieO's 4 compartment Raaco drawer insert. Allows 2 stacked on top of each other in one drawer.
I quickly modded Gildef's raaco drawers and make a taller Version that fits some raaco cabinets. ( older version with clear polystyrene (?) drawers ) approx. 67x64x139mm ( excluding handle, including tab on the back ). The shape is not…
All regular sizes from 1x1 (width x depth) units to 10x5 units for the 55, 80, and 150 series of boxes. No supports needed. As of version 2.9.3 PrusaSlicer does not bridge the inner cutouts well. Add a modifier box over the cutouts that…
A nice and organized way to store your EXFO FIP-500 tips. Designed to fit a Raaco Assorter 6-0 (https://raaco-direct.eu/detail.asp?Lang=1&Prod=110672) Printed at 0.2mm layer height. Printing the inserts in different colors can be a easy…
I have a wall with multiple Raaco 3-160 boxes. Some of the boxes are too big to use for single item. I made a simple divider which press-fits directly into the boxes.
1:1 copy of the original space divider if it doesn't fit i uploaded the step file too, so you can make easily changes. dimensions: 66x35x4 I kindly ask you to leave a like and comment with pictures of the print
My first ever creation. I created these because my cabinet was missing two drawer units, and these fit perfectly with a functional lip to prevent them from sliding out too far or falling through. Technical Specifications: Height: 37mm…
Description These clips can easily be fitted over the latches on Raaco "Service Case" and "Assorter" cases to prevent them from opening when your suitcase is being thrown around by airport luggage handlers. They simply clip on, so they…
These will be stackable and still fit perfect in Raaco Carry Lite 55+80. If you have a 55, then you need a total of 2 high. So either 2x1High or 1x2High. For 80 you need a total of 3 high. Print with no supports. As of now, I only need…
I modified the original, so that the thin parts that goes into the wall/board does not break as easily. This is the M5 version I recommend you print in the orientation shown, so that it improves the strength of the weakest points even…
Boite de rangement pour tiroir Raaco 2 STL inclus : petite et grande boite FreeCad Parametrique inclus (modifier la feuille de calcul pour mettre vos diensions) Impression Sans support
Inspired by Bdenouden, I've changed the model to better suit my use case. I've removed the magnet holes as I don't use them and changed the output mechanism to use tweezers or pulling the cover tape to get components. It can hold around…
This is a replacement drawer that fits it into approx. 150mm deep small parts storage cabinets made by Raaco or Mars Svratka. This model is not made to be an exact copy of the original but rather a functional replacement that is optimized…
Found a Raaco Service Case 17 with a missing latch. Designed quickly so not super fantastic looking, but it's tested and works as expected. Also prints without supports. The little inner tab thing that locks it in place is pretty thin so…
Easy pegs for Raaco Tool walls Can be secured with a 3x10mm Hex Screw. Differents Length: 25mm. 50mm. (Used in pictures.) 80mm. 100mm. Perimeters: 4 Infill: 50% No support Needed
I didn't have enough dividers for my Raaco drawers, so I made a model for the dividers I could print.
Designed for Vase mode printing - faster and minimal material usage. Settings for printing: Larger layer heights work well - I used 0.35mm, (choose 0.2 then increase to 0.35 for the Prusa Mini) Enable Vase mode & accept the recommended…
Spacer for Raaco Drawer. width bottom 63 mm width top 64 mm height 31 mm Print Settings Printer Brand: Prusa Printer: i3 MK2S Rafts: No Supports: No Resolution: 0.15mm Infill: 15% Filament: Purefil ABS Orange Category: Organization
This is a A8 sized Insert for the RAACO Assorter Series55 Boxes - the most used size if you store screws and similar small parts. It is designed in a similar size like the original inserts including the tapered sides. Prints without any…
Printed with minimal supports, and no draft to the walls.
I print mine in clear PETG but most materials will work just fine.
Printed with minimal supports, and no draft to the walls.
Remix of the Raaco drawer insert by ArnieO. I needed it for even smaller parts and quantities, so I intended to put two in one drawer. 16mm tall for each drawer.
Separator for raaco drawer Print flat on print bed Model Printed in PLA Feel free to share, remix it as it's a very simple design and could probably be improved
These containers are designed to be compatible with the grid in the Raaco 55 and Raaco 80 system. So they can be used in your existing Raaco handyman or Raaco Carrylite / Assorter boxes. The grid is also included with the pack so that you…
Raaco organizer box for the famous boxes we all use in our workshops for sorting screws and stuff. Raaco Sortierbox für die Sortmientskästen die wir alle in unseren Werkstätten verwenden um Schrauben und andere Sachen zu sortieren. Print…
Those are lids for Raaco Boxxser insert A9-1. Because the polycarbonate cover is not tight enough for really small hardware like small washers. Print Settings Printer: CR-10 V3 Rafts: Doesn't Matter Supports: Doesn't Matter Resolution:…
I have been using Raaco Handyboxes for component storage and transport, and find a lot of space in them is wasted as I do not have enough of the small inserts, and also the smallest ones could have more compartments to save even more…
The Raaco assorter boxes seem to fit perfectly into a Kallax shelf. So why not make a rail to be able to draw each one out individually? The thin vertical bars help with assembly if you want to stack several rails on top of each other.…
Replacement drawers and dividers for an old organizer bin made by Raaco. Printed in Clear PETG w/ .3 layer height.
Simple wall-divider for Raaco storage cabinet. Raaco makes at least three different sizes of drawes. This is the small version.
Racco Erweitung Paket für CNC Inlay und CNC Vorlagen von Grid. Grössenwünsche druchgeben werden dannhochgeladen :-)
The raaco metal storage cabinet comes I bought came with 44 bins and a few dividers. I needed more dividers and found the model by jdpp44 on Thingiverse. The original bin dividers had an up marking for easy/even easier installation; the…
Mit diesem Doppelfach lassen sich größere Teil in einem Raaco 1248 Magazin unterbringen. Es gibt zwar in der Mitte eine kleinen Steg, der bei vielen Teilen aber nicht stören sollte. Drucken, Print: no support, print small walls, wall line…
A 3-slot divider insert for Raaco A8-1 box (55 series). I used it to organize my resistors. Category: Organization
A spacer to use Raaco system 55 inserts in system 80 box. I use a lot of Raaco boxes to organize connectors and pins for automotive wiring harness building. Storing small pins in the smallest 80 system bins (BA8-1), makes it a struggle to…
A screwdriver rack that sits nicely onto the Raaco tool wall panels. Can be locked place in using a 3x10 mm screw. Print instructions To print this you need 3 parts. 2x Single Universal Clip 1x Screwdriver rack Print with PETG - 4…
Design is based of the original mountings. The holes are made to tap or self thread a bolt size M5 or M6 in to it. Be careful removing the supports when you are printing in the same orientation ;-)
This model is based on the original Raaco Super Clip. You need to add a L-hook yourself. I used a L-hook from Amazon that is perfect for this. No idea if it is available for everyone. Printposition: as show in picture Material: PET of PLA…
A rack for flat tools like files, chisels or scrapers that sits nicely onto the Raaco tool wall panels. There is a version with 4 slots and a version with 2 wider slots. I have found the one with 2 slots the most usefull so far. Can be…
RAACO Assorter 55 boxes are excellent and are my preferred storage for small parts. I was a bit space limited and wanted to fit more boxes into the space where six handy-box frames fitted previously so I made these double side mount…
Paramteric drawer insert for Raaco/vector cabinet. Holds SMD parts in mini containers / micro tubes / centrifuge tubes. Can be resized for other drawer sizes or container sizes, or to hold e.g. batteries etc. or to hold less or more…
