A modified model of Kunzite's beautiful container for the Ikea Skadis pegboard.
I have created a parametric model to create any size.
Sizes
The size of the containers is described with “units”.
1 unit:
- default base is 39.5x39.5mm
- default height is 32mm
- larger sizes are multiples of 20mm
Prepared sizes:
- 1x1x3 = 39.5mm*39.5mm*72mm
- 1x2x3 = 39.5mm*59.5mm*72mm
- 1x3x3 = 39.5mm*79.5mm*72mm
- 1x4x3 = 39.5mm*99.5mm*72mm
- 2x2x3 = 59.5mm*59.5mm*72mm
- 2x3x3 = 59.5mm*79.5mm*72mm
- 2x4x3 = 59.5mm*99.5mm*72mm
- 2x2x4 = 59.5mm*59.5mm*92mm
- 2x11x1 = 59.5mm*239.5mm*32mm
In the parametric model, edit only these parameters:
Printing:
- Need support
- Nozzle: 0.4
- Layer: 0.2
- Perimeters: 3-4
