Slime VR Tracker

I wanted to have my tracker as small as possible and light.
I could not find a model to fit a DIY build small enough so I made this.

For the people who don't know what it is:
https://docs.slimevr.dev/index.html
https://www.crowdsupply.com/slimevr/slimevr-full-body-tracker

SlimeVR is a set of open hardware sensors and open source software that facilitates full-body tracking (FBT) in virtual reality. With no base station required, SlimeVR makes wireless VR FBT affordable and comfortable.

Print recommendation:
Tough PLA
Layer height 0.2 or 0.1
Supports: No
Walls: 3
Infill: N/A

I was inspired by this model:
https://docs.slimevr.dev/diy/cases.html#slimex-fdm

It uses the same components except for the switch.

Here is the list of the components and the link for each of them:
(please note that the Aliexpress pages are only for reference. It's recommended to look for other offers yourself.)
Wemos D1 Mini V4 Wifi Board
TP4056 USB-C Charger Board
SS12D00G3 3MM Switch
BMI160 IMUs
804040 Li-Po Batteries
28AWG stranded silicone wire
Elastic Band 40mm 5Meters
Diodes 1N5817
180K Restistor

Tracker Schematics


I recommend this soldering order:
(You can follow any, but 1 to 5 orders are mandatory if you want to make you life easy)
