I designed this for the random components that come in plastic/divided cases that I wish had a standardized form factor.
Limits: only has 12 divisions per drawer with a height based on the shell dimensions (see below).
Small drawer-based chest to store electronic components (or beads, I guess). 4 Drawers, each with 12 dividers and real estate to label.
Dimensions of whole unit: 106(width) x 89(height) x 183(length) mm
Dimensions of drawer: 99.5(width) x 19.5(height) x 180(length)
Dimensions of each organizational section: 43.13mm x 31.17mm x 18mm (h) (mind the chamfer that mitigates need for supports but encroaches on volume)
Size of label area: 31.17mm x 10.11mm (each width of label ledge spans the whole drawer[99.5mm] and 12mm labels seem to fit ok)
