Deep Impact Socket Carrier
Order a print of this model
We calculate the final price from your selected file. You review and accept it before payment.
Saved on this device.
Tray for Harbor Freight Deep Sockets
- Rating
- 0 / 5
- Likes
- 2
- Downloads
- 38
- Makes
- 0
- Views
- 202
- Reviews
- 0
Updated at source:
Model information
- Source
- Printables
- Category
- Organizers
- License
- Creative Commons — Attribution — Noncommercial
Carrier tray made to fit in tool box that has an extendable handle the carry around. Fits Harbor Freight PITTSBURGH 1/2 in. Drive Metric Impact Deep Socket Set: 10mm, 13mm, 14mm, 15mm, 17mm, 18mm, 19mm, 21mm, 22mm, 24mm, 27mm, 30mm, 32mm
Assembly Material:
QTY 4: M3x0.5 Nuts
QTY 4: M3x0.5x40mm Bolts
Filament:
PETG
Supports:
None
Infill:
15%
Brim:
Yes (As Applicable)
Printing Notes:
- Had to split the Top_Rev2.stl and Bottom_Rev2.stl parts in half to fit on my build platform Prusa i3 MK3S+
- Print QTY 4 of the Post_Rev2.stl
Assembly Instructions:
- Insert the bolts through the Top_Rev2.stl on each counter sunk corner.
- Slide Posts_Rev2.stl over each of the bolts on each corner.
- Insert Handle_Rev2.stl in middle cut out of the Top_Rev2.stl from the bottom up.
- Insert bolts through Bottom_Rev2.stl on each corner.
- Add nuts to countersunk holes under the Bottom_Rev2.stl on each corner.
- Hold nuts with needle nose pliers while tightening the bolts with an Allen wrench (DO NOT OVER TIGHTEN)
- Add Sockets and DONE!
Note: If the Handle/Sockets are tight fitting, a bit of sanding might be necessary (Printer mileage may vary)
