These fittings will allow you to make a Reef Hub for the 2025 FRC game Reefscape out of PVC pipes. Each fitting is split in half to allow easy printing and alignment of the layers for maximum strength. Glue everything together with hot…
These are scale models for teams to print and use in their design discussions. Print 6 reef bases and interlock them. Print 12 Reef Trees to add to the bases. Print as many robot parts as you want :)
A Raspberry Pi mount I made for a robotics competition that is press-fit or screwed-on to attach the pi to the mount and zip-tied or bolted on to attach the mount to the robot. Has M5 holes for mounting. This mount is designed for the…
Design and instructions for the poles for the reef field element for FRC 2025 ReefScape competition. As you may know all the websites that sell the elements are sold out. We thought that PCV would be a bit flimsy so went with 1.5" solid…
Each branch of the reef structure can be created from PVC pipe and these joint elements. The lengths of pipe needed for a single reef component are: 23 7/8 inch (bottom) 9 inch (lower branch, level 2) 9 inch (upper branch, level 3) 12 ¾…
Check out my star wars models as well as FRC robot files. full R2D2 model on the way. -All made on Onshape The robot base as well as the elevators height and width change based on chosen variables. Check out this robot on onshape….…
This is a mini reef model to use for strategy discussions (or just for fun) for the 2025 FRC game - REEFSCAPE. The model is a 1:12 scale with a few modifications: Reef branches are thicker than 1:12 for strength. The coral are slightly…
I designed these brackets to be glued to the pvc pipe while also screwing them down for more strength. These are for FRC field build instructions ( two of the top pieces are required for L4 ).
This is a measuring tool that will help you identify if any poles on the reef are not correctly aligned according to the field spec. The gauge has 3 settings 0.25", 1" and 2". In hindsight it only needed the 2" option. To use, place the…
FRC 2025 reefscape reef with step files will add more game pieces soon as of 3-20-25
This is a 2in Vectored Intake Wheel(mecanum wheel), Features a 1/2in hex bore. Hardware: 2x 3/4in 6-32 bolts 2x 6-32 nylock nuts Printed out of PLA, but has not been tested on a robot.…
Keychain to celebrate the 2026 FIRST Robotics Competition Rebuilt game. Model created by FRC team 5353 LoCo Raptors, proudly sponsored by Printed Solid. Model printed in Jessie Premium PLA - Vanilla Bean Ice Cream.
Snap-on spacers for 3/8" hex shaft. Easily change spacing without removing all items from a shaft.
V2 brings hex head tightening locations and makes the auger one piece
Print out of solid petg can withstand .8 imperial tons of force at thinest point
Created with Fusion for FRC 2026 Team 5137 Iron Kodiaks. Intent of the model is to allow for a flat base plate that can be used for 3M adhesive velcro or zip-ties, as well as having room for bolts to thread into a breaker shroud .…
spindexer agitators for team 3082. The mechanum wheel casing and dome were the least efficient for weight and speed but the 2 cones were pretty comparable. printed out of pla but could be printed out of anything. use 1inch 10-32 button…
A remix of FRC3038's camera mount for better camera fit/hold and more istall options. This is a WIP (ver 2); Version 3 may have print-in nuts for the tilt axis to elliminate the need for the 3.5"+ tilt bolt
This fits the new FRC radio and is designed to hold a 60 or 80-milliamp fan it blows air through the built-in ducts and pumps it out the sides. fan link:…
1/2in Hex Bore 10mm Major Thickness 15mm Center Thickness 121mm Diameter
Useful for verifying that the load cell fits in your application before purchase/delivery.
This design is easy to install and does not need any disassembly for the installment process
This is a mount for the FRC VH-109 (WCP-1538) radio. There are two versions, both of which are designed to mount on a 2"x1" box tube extrusion with predrilled holes. For the first, the mounting holes are on the 2" surface of the…
Designed to be paired with 3 noctua fans. We used an oscillating saw to physically cut passthrough holes in our radio. Use extreme caution to avoid cutting internal antennas and wires. This should only be done on a radio to serve as a…
Large Drink Coaster I designed in honor of FRC Team 2834, The Bionic Black Hawks. https://team2834.com/ Two sizes: 106mm and 111mm
A bolted mount for a vividhosting FRC radio, allows for the removal of the radio from the robot without cutting zipties. Useful for flashing radio at events without wasting zipties. Print with team numbers facing upwards. No supports.…
Mount for Limelight vision to FRC robot chassis
The intent was to minimize wiring & eliminate the unreliable JST connectors used for the CAN Bus system used in FRC robots & at the same time allow SPARK MAX modules to be mounted in such a way to allow a clean neater CAN bus…
This is a bolt-on mount for REV Robotics Spark MAX motor controllers. This version accepts #8 bolts to mount to any flat surface or can use existing hole to tie wrap the base in any desired location. You can use the bolt holes underneath…
Check out my other star wars models as well as FRC robot files. full R2D2 model on the way. -All made on Onshape
Check out my star wars models as well as FRC robot files. full R2D2 model on the way. -All made on Onshape -Check out this model in onshape……
Check out my star wars models as well as FRC robot files. full R2D2 model on the way. -All made on Onshape -Check out this model in onshape… Let me know your thoughts…
A 3d printed case for the radio used for the FIRST Robotics Competition. Tested on Team 5135's 2020 and 2021 robots. Category: Robotics
End Caps for Open V-Slot 2020 with Open Hardware logo. This is a remix from https://www.thingiverse.com/thing:398515 Print Settings Printer Brand: Creality Printer: Ender 5 Rafts: No Supports: No Resolution: 0.2 Infill: 20% Filament:…
End Caps for Open V-Slot 2020 with Open Hardware logo. This is a remix from https://www.thingiverse.com/thing:398515 Print Settings Rafts: No Supports: No Resolution: 0.2 Infill: 20% Filament: Prusament pla Notes: Any material does the…
During the 2024 FRC season, I needed a gear reducer for the NEO motors. All of the commercial options were either too expensive or out of stock so I developed my own planetary actuator. 4:1 planetary gearbox Neo motor bolt mount pattern…
Requires use of the Spline XS 3D print adapter WCP-1021 from WCProducts.com Highly recommend printing with filaments that support mechanical resistance. PETG at a minimum, PA11 Nylon preferred
Requires use of the Spline XS 3D print adapter WCP-1021 from WCProducts.com Highly recommend printing with filaments that support mechanical resistance. PETG at a minimum, PA11 Nylon preferred
Components for the creation of a compact belt driven elevator primary using 3d printed parts with main frames made out of 1/8" thick 2x1" aluminum tubings. Components modified from OnShape CAD models.
BUILD SEASON 3D Print replacement for SDS MK4n L2+ gears. 18T SplineXS Drive gear requires a WCP-1121 3D print adapter. 2024-01-08 UPDATE: Denbot MK4N L2+ 26T 52T 20DP Double Gear bearing clearance updated after finding the wrong value…
This is a scale model of the 2025 FRC game field for Reefscape. I designed it to be scaled down to 4% (Yes 4, not 5). I used pieces of standard 1.75mm filament to connect the parts. Be warned; I haven't finished printing the barges in the…
Appreciated the efforts of Kyle but wanted solid 3D prints.
This model was made as of the 5.7.2 update. It is 16.25in in diameter so you know if it in the 16-16.5in range. Convenient grip and made for 3D printing.
From team 5885, the Villanova Wiredcats: Unless specified on the PDF, you can print these in the orientation they come in, without supports. Magnets needed: 2 - DIA. 1.26" x 0.12" Magnets 21 - DIA. 8mm x 3mm Magnets Printed with Polymaker…
Cage earrings to celebrate the 2025 FRC game REEFSCAPE! Customize with some extra jewelry chain to switch from shallow to deep cages. Printed at a .12mm resolution on its side at 100% infill and 4 walls, printing it vertically will put…
This is an over the top style mount for the VH-109 FRC radio. It was designed to not cover or interfere with any functionality of the radio. Lights are visible and ports are clear. Minimal amounts of the radio are covered to allow air…
BUILD SEASON 3D Print replacement for SDS MK4n L3+ gears. 18T SplineXS Drive gear requires a WCP-1121 3D print adapter
BUILD SEASON 3D Print EXPERIMENT for SDS MK4n L4+ gears. 18T SplineXS Drive gear requires a WCP-1121 3D print adapter
After a long journey through Chief Delphi, Thingiverse, and all sorts of weird vendors, trying to find an easy to print, highly functional Vectored Intake Wheels for FRC robots... I have given up and decided to design my own . . . A bit…
This is a robot signal light mount for FRC robots. I designed this for my FRC team (4926 Galactech). It mounts on a 2x1 and you have to use 10-32 bolts to attach it. The width of the hole is 0.886 inches. This is specifically for a robot…
Pulley wheel with a 3" outside diameter and 2" inside diameter Two flanged 1 1/8" bearings can be press fit inside
3D Printed parts for FRC team 3038's Coral Intake mechanism. Our mechanism consists of QTY 2 of 3038-25-P-09-003, QTY 1 of 3038-25-P-09-004, QTY 1 of 3038-25-P-09-005, QTY 1 of 3038-25-P-09-006, QTY 1 of 3038-25-P-09-007, QTY 2 of…
3D Printed parts for FRC team 3038's Shallow Cage Climber mechanism. Our mechanism consists of QTY 1 of 3038-25-P-00-021. Printed in PETG.
3D Printed parts for FRC team 3038's Coral Outtake mechanism. Our mechanism consists of QTY 1 of 3038-25-P-05-007 and QTY 2 of 3038-25-P-05-008. All parts printed PETG.
Handle designed to be mounted to REV Robotics Max Tube or Andymark AM14U5 KOP chassis. Mounts with 10-32 1" long bolts. 4 handles could support a 115 pound robot (~150 lbs with Battery and Bumpers). Material: PETG Infill Density: 15%…
Snap on spacers for 1/2" hex shaft. Printed in either PETG or PLA.
Handle for easily picking up FRC Robots. Stop print midway through to capture 10-32 locknuts . Designed for bolts to go a half inch into the print. We used 4 of these handles with 2.5" 10-32 bolts and mounted directly on our frame. Holes…
This handle quickly clips on and off of the 18 Ah AGM batteries used in FRC robotics, reducing the chances of someone lifting the battery by the cables. More details are shared in the Chief Delphi thread below.…
This model features 1" bolt spacing on the frame rail mounting section, and space to fit two Rev Spark Maxes, with their standard covers, through bolted.
3D Printed parts for FRC team 3038's Elevator mechanism. Our mechanism consists of QTY 5 of 3038-25-P-08-011, QTY 4 of 3038-25-P-08-014, QTY 6 of 3038-25-P-08-015 (in TPU), QTY 2 of 3038-25-P-08-023, QTY 2 of 3038-25-P-98-045, QTY 2 of…
Mountable strap holders to be used with a battery mount like https://www.thingiverse.com/thing:3506733. Two copies of the object, one with a narrow slit and one with a large slit - we kept the narrow one permanently connected and used the…
Remixed from the awesome fidget by Thorin Oakenshield. We added Team 4405 Atom's Family logo and team number to frame. The gear is the same as source model.
I made it fit a 7/16th socket so we could put a 1/4in bolt into the top Printed out of elegoo pink pla
Ultra lightweight and some of the smallest mechanums available. Print in PETG.Ream all the roller shaft holes with an 1/8inch drill bit and hand drill. Ream the two screw holes with a 3mm bit. Ream all the roller holes with a 3.5mm bit.…
Mount for a FRC break beam sensor. Intended to mount with 3M VHB tape. Can be printed out of PLA or PETG.
Mount to mount the main breaker for a FRC robot. Printed in PLA.
This is the Cage from the FRC 2025 REEFSCAPE season! With the up-and-coming FIRST Championship! Print to show your support for the amazing FRC season!! If you liked this model leave a like or comment to support me! :) HOW TO PRINT Print…
Use 10-32 bolts to mount the roboRio to the PDH. The holes on the mount are to secure the mount to the roboRio. Best printed with stronger materials and settings
Helpful for laying out electrical components on a bellypan while being conscious of wires and strain relief.
This is a 1:16 scale model of our 2025 robot, Cold Front! The robot is printed as a single part. Files for the two main Game Elements, Algae and Coral, are also included. Material: Robot: Printed in Creality Blue PLA…
Robot Dance Party 2025 Edition! Host a Robot Dance Party in the Off Season for your FRC, FTC, or FLL team. These Trophies are made using 3D printer and Laser Cutter (Hangar and Plaque). Parts: https://amzn.to/4m0SDXb…
50% Gyroid infill works best for traction in our studies, the tire is made out of TPU and the hubs are made on Markforged Onyx printers. Used for West Coast SwerveX modules.
This is a 2in Vectored Intake Wheel(mecanum wheel), Features a 1/2in hex bore. Hardware: 2x 3/4in 6-32 bolts 2x 6-32 nylock nuts Printed out of PLA, but has not been tested on a robot.…
This battery door was created in FreeCad using digital caliper measurements on an original Zoom FRC-8 battery door. Test prints were done using basic PLA filament. For best printing, you may need to rotate the model in your slicer. The…
This helmet was orignally made by me for FRC Team 6996's Koala Mascot that we have on the side of our robot. The ziptie slot fits a ziptie of 4.7mm wide and 1.2mm thick, it will fit most ziptie slots, and there is a spot for the ziptie…
This is built for a 12v battery box panel using a marine fuse as the main breaker. This will allow it to be dropped behind the surface cover on the box while leaving function available externally. M4x10 inserts
Pulleys with Hex Center designed for HTD 5 Belts. Motor specific files have lip to ride on inner race of bearings to not have wear. Number of teeth inserted on side of the pulley.
Pulleys designed to be used in FRC, specifically used with HTD 5 belts. Number of teeth inscribed on side of pulley
You can mount it to ur wall and display FRC/FTC or other pins as you want. Large pins require empty space directly above them, or a mounting plate. NOTE: This version does not accommodate smaller pins. A version for these small pins is…
Enclosure for the BIFRC Servo Trigger Controller Module. Attaches magnetically to the, f. ex. the Core ONE body, for flexible placement. Additional parts required: 1x BIFRC Servo Trigger Controller Module 1 4x Brass Insert Nut M3x5 4x…
General This is a replacement for the Land Rover Series Gearbox Top Cover Gasket (FRC3776) which is often only available as a cork gasket. You can scale the z-height of the model if you need the gasket to be thicker or thinner or you can…
The goal of this model is to inspire people to create their own XRP scale version of FRC Reefscape Robots. Find the reef parts here: https://www.printables.com/model/1140627-frc-reefscape-reef-and-game-pieces
A holder for CAN Di that could be mounted onto a 1x2 MAX pattern tube. It needs to be used with 4-40 screws and nuts.
A CAN Range holder that can be mounted onto a 1x2 MAX pattern tube. It needs to work with 4-40 screws and nuts.
This is a remix of the BIFRC DH20 Pro+ Stand model by MekoZeko: https://www.thingiverse.com/thing:4847279 I added a couple of supports between the probe end holders and the main body. I also added a couple of supports on the back of the…
FIRST Robotics Competition (FRC) 2020 Game "Infinite Recharge" - Printable Logo
A novel approach to battery mounting and connections allowing teams to not worry about free floating battery wires and excessive force for sb50 connections. More information in the Chief Delphi thread here:…
We loved Team 1294 - Pack of Parts, battery case handle and even built a battery box and cart around it. However after a year of abuse we found areas where the design lacked durability. This version is improved addressing areas where the…
I needed a reliable, repeatable way to mount official FRC AprilTags while keeping them easy to swap out. The bracket requires two M5 heat-set inserts and is designed for M5x10 button head screws. I specifically used the CNC Kitchen…
FRC Battery flags compatible with my FRC Battery autoconnect system Onshape link: https://cad.onshape.com/documents/2953e92328aa90e7fc1d5463/w/cd3960a58976c716de9c0981/e/d990decdbeefe09652e1470d I printed these with cc3d rigid tpu for the…
This is a 3D-printable hex nut designed for the FIRST Robotics Competition (FRC) Robot Signal Light (RSL) , which uses a 7/8″–24 UN thread . Thread spec: Unified 60° profile, pitch = 1.058 mm , major diameter = 22.225 mm (7/8″).…
