These are electronics mounts that fit in my Duender Base Case . Currently there's a mount for a Raspberry Pi, an ender 3 control board (or anything that with the same form factor) and a mount for the ender 3 power supply. If you have cut…
I had a ender 3 pro, not an ender 3, well i should say two ender 3 pros instead of 3s, but anyway, i wanted it for a pro version, and the remixes availble are not helpful, or are not the full files, so i present my full pirnter in cad,…
A very oversized (and strong) Z axis mount
This is an arm to hold the Bambu nozzle brush for use with the Duender. It is meant to go with the side mount bracket from the DuEnder MGN9H's Extras folder
Here is a Klicky dock mount for Duender and Duender MGN9 edition. This is spot on for my setup, using Xol toolhead in both cases. I'm using a pair of screws and ship nuts through the top slotted holes for mounting, with the option to use…
An LED Light Bar for the DuEnder. Mounts along the side of the 2040 Extrusions used for the Y axis. Will only work with DuEnder projects that use linear rails. Mounts to the 2040 extrusion using three M3 bolts and t nuts. It has holes on…
I printed this in ABS .6 Nozzle DuEnder Printer 270 degree nozzle 90 degree bed PEI build plate
EMS Panel [Edit: The overall dimensions of the panel have been adjusted to give a better fitment. The original version was too tight, although with some effort it could be forced into place. I have also extended the tabs so that they bolt…
A somewhat lazy take on a top plate for the DuEnder base case. The lid it 330mm on it's largest side, so it'll require a large format printer to print whole. I imagine it would be fairly simple to break it up into parts and glue it. I…
Print in any filament no supports slowly and have maximum cooling
This is a webcam mount primarily made for the DuEnder project. The reason I made it is because with this form of CoreXY printer, I was having trouble the webcam shaking violently during printing, causing bad video quality. This mount…
I modified the Raspberry Pi mount for the Duender Base Case to fit the holes of the BigTreeTech Pi v1.2. So if you need that specific model, here you go.
Version 2: Added a version 2 because i felt like it wasn't secure enough on the extrusion. I added a spot for an M5 screw and t-nut on the top to attach to the 4040 extrusion. Remixed the original Wider Duender motor mounts for 4040 y…
Duender Front mounts for 4040 Extrusions (Mirrored Remix). My Linear Rails are on the outside of the 4040 Extrusion so i mirrored the original stl to accommodate for this.
OUTDATED VERSION This version is no longer maintained. Please use the current Duender Project: Printables: https://www.printables.com/model/1798903-duender-project-ender-3-to-corexy-conversion https://irbis3d.xyz/ GitHub:…
This electronics box will allow you to add a 2 or 3rd MCU to your DuEnder. It is compatible with both the single or my double MCU box. I have not printed it myself yet so if there are any errors please let me know.
OUTDATED VERSION This version is no longer maintained. Please use the current Duender Project: Printables: https://www.printables.com/model/1798903-duender-project-ender-3-to-corexy-conversion https://irbis3d.xyz/ GitHub:…
This project contains a re-design of the front tensioner housings from Sergei Irbis, and they re-use the stock pulley holder inserts. The main change is that it uses the M5x45 and M5x25 bolts from the Ender 3 (you need to tap your threads…
This is the mod I first started working on. I was looking for options not to have to buy a sheet of aluminum then drill and cut the plates. I used purchased open-build plates for the Z axis, but this doesn't work for the X gantry. I…
This is my version of an AWD DuEnder. The rails are all MGN9. When I get the chance, I will update this description with a parts list of used hardware to assemble, but most everything is an M3 bolt ranging from 5mm up to 35mm. Print…
There is a gantry plate for an MGN12C and MGN12H linear rail The ABL mount and the fan duct plate are slotted for adjustability. The ABL mount is designed for a CRTouch, unsure if it works with a BLTouch. There is an optional mount for a…
X Mount MGN12 This mod is for Duender MGN9, however it confusingly supports an MGN12 rail on the X axis. Doing this expands the toolhead options as effectively any Voron toolhead will simply fit as-is. I have a StealthBurner on mine, and…
These are 4040 Extrusion Mounts that are compatible with the changes I made for the Wheeled Hybrid Model below.
Simple extrusion mounted umbilical + ptfe tube holder for the duender. Use with PUG cable strain relief https://www.printables.com/model/378567-pug-parametric-umbilical-gland
The Duender logo by @coldstorm as an STL, so that you can include it in your designs where you see it fit :-) It's centered on the origin, so you should be able to easily place it wherever you want and scale it to size. The original logo…
This is an arm to hold the Bambu nozzle brush for use with the Duender. It is meant to go with the side mount bracket from the DuEnder MGN9H's Extras folder
Uploading this as basically just ideas for another way of doing things. This came to me when I was disassembling the Ender 3 V2 and noticed there was a lot of decent flat sheet metal stock. I happened to have a pair of aviation snips/tin…
Integrated belt tensioners/Medusa HC mount for the Duender and Medusa HC hotend changer by Sergei Irbis. Replaces the stock tensioner from the MGN9H Pins version and the Medusa HC mounting. No more glue!
Integrated belt tensioners/Medusa HC mount for the Duender and Medusa HC hotend changer by Sergei Irbis. Replaces the stock tensioner from the MGN12H Pins version and the Medusa HC mounting. No more glue!
A remix of the Klicky Probe mount for the Voron 2.4 to adapt it for use with the Duender Medusa HC by Sergei Irbis.
Base Case Cover for the Duender MGN12H Edition . Panels are fixed together using brass threaded inserts and M3x12 Screws
This is a Trident alternative mount for the Dragonburner to fit the Duender. And a stopper that mounts on the X Right Mount. Extra Hardware: 1 x M5x16 Hex Socket screw to mount the stopper 2 x M2.5 x 20 to mount the switch to the mount
I recommend using ABS, ASA or at least PETG. You need to cut the tap which hits the endstop from the original mounting plate. Installing is also very simple. Screw the printed adaptor onto the linear carriage using m3 screws. Now bolt the…
A swingarm dock and toolhead mount for the Medusa HC and/or Duender. May work on other printers as well. BOM:
This is feet for a duender if like me you want to keep the rubber stuff but print quickly and use the z motor spacer its a little ugly it uses m5 screws btw your printer doesn't have to be precise for this
I needed an extended 4040 top mount for the z axis. Uses 4 M5's and t nuts to mount and 1 to screw into the extrusion. If you're feeling generous: https://buymeacoffee.com/lascius3d
Add a adjustable stock limit switch to the Y motor bracket You need 2x M3x5x4 heatinsert and 4x M3x12 screws+bolts to mount the Ender switch to the Y motor bracket/holder. The switch gets triggerd by the extrusion
I didn't liked the idea of visible split in the front skirt - so I've made this remix. Now the emblem is seperate part prepared for gluing into made space. I'm waiting for material spool to print it myself - so untested how well will it…
This is designed for a stock Duender with a Z spacing of 97mm. Feel free to chop it up and make it yours however you see fit.
same directions as MGN12 mount for the Creality Sprite Pro Extrude add 2x m3 thread inserts and screws for belt retainer I wanted this so I figured other people might want it too so here it is I am unskilled and doing the best I can so…
Had extra 300mm extrusions, put them to good use.
My project was an Ender3, and an Ender3 v2. One of them came with larger rubber feet with dimensions approximately of 39x19.6x12mm. Additionally, I didn't want to cut the threaded rods. I used the Duender Z Motor Spacer found here:…
OUTDATED VERSION This version is no longer maintained. Please use the current Duender Project: Printables: https://www.printables.com/model/1798903-duender-project-ender-3-to-corexy-conversion https://irbis3d.xyz/ GitHub:…
Allows for a length of MGN12 rail to be used instead of cutting a 2020 extrusion down for the X gantry. Up to 3 mounting points are available each side for mounting the rail, and 2 points each side you mounting onto the Y carriage. My…
I printed out the original box before checking and the mounting points were to close to the wall to match the 3b+. So a few hours later I made my own and added mounts for a DC voltage converter if you want to run the Pi off of the 24V…
Another remix for the electronics box. Most of us have spare MCU laying around. This box holds 2 Ender 3 MCU ( or same hole pattern) allowing you to designate the 2nd one in Klipper and use it for the Z access control. Doing so will allow…
This is a bracket used in conjunction with the original Creality Sprite mount. You will need to cut the x-axis end stop tab. Print: ABS 50% infill or more 3-5 walls 4 heat insets required for belt tabs I used M4
A remix of the DuEnder build plate carriage to allow the use of the common open build 2020 plate. ( as pictured in gray) I recommend connecting to the carriage with 4x M5 x16 Pan head bolts w/ lock nuts
This electronics box will allow you to add a 2 or 3rd MCU to your DuEnder. It is compatible with both the single or my double MCU box. I have not printed it myself yet so if there are any errors please let me know.
Sometimes the hotend wires rub against the rear span of belts, so I made this to protect the belts. This mounts to the rear horizontal extrusion of the Duender with 3 M4 bolts, washers, and T nuts.
Just a plate to adapt the Dragon Burner v8 toolhead to the Ender 3 with paths for belts on a DuEnder
Can fit on the duender just remove the M3 bolts closest the to large bolt holding the old ender ther x/y axis pulleys.
Print in ABS OR PETG 3-4 walls at >20% infill no long a need for bottom 5m bolt connected to the aluminum plate
Printed at 100% infill 3-4 walls in ABS when assembling x axis gantry put this plate on top of it and thread the bolt through this and the aluminum plate after connecting and stringing belts
This is an aesthetic base case for the Duender, with inspiration from Voron. It has 2 fan slots in the each of the side skirts, along with some optional fan spacers if you want to use 2 on one side. There are cutouts on the bottom of the…
https://www.printables.com/model/1174545-duender-2x-creality-ender-3-corexy-convertion Most of the build is the same as the original Duender. Use the Duender STEP file alongside this one to figure out the build. The BOM from there should…
A rear mounted aux part cooling for for the Duender. 2 versions included, one for nozzle height for the dragon burner and one designed for the original CAD of the Duender. The fan i used in the model was a Axial 6015 fan but you can adapt…
My take on the Duender by Sergei Irbis. This version uses MGN12 linear rails with H size bearing blocks and adds mounting points to use end stops if you prefer those to sensorless homing. For the configuration I used, you will need the…
This is my take on a toolhead for the Duender. It uses an H2 V2S Revo extruder from Biqu and takes inspiration from the EVA 3 system for wrapping the assembly around the gantry and placing the part cooling fan on the back. This toolhead…
These tensioners just add a bit of clearance for the belts and toolhead no supports are needed
OUTDATED VERSION This version is no longer maintained. Please use the current Duender Project: Printables: https://www.printables.com/model/1798903-duender-project-ender-3-to-corexy-conversion https://irbis3d.xyz/ GitHub:…
This is a Klicky dock mount for the Duender , I am using it with PCB Klicky on an Xol toolhead. In the files I have included an unmodified file from Better Dock for the PCB Klicky Probe , but it should work with the og Klicky Dock as…
Uses F695-2RS Bearings Now added a MGN9 Version with all M3 bolts thanks to SlickChris from Discord! Also added a roller version with all M3 bolts.
A simple z motor spacer for the Duender if you want to avoid cutting your leadscrews, its 14mm and works to space the leadscrew enough to avoid hitting the nozzle on most toolheads. It works with my base case and base electronics mounts .
This is a modified electronics books to be able to Mount the Manta E3 EZ control board.
Reuse an Ender endstop for your Duender y axis: use the printed part to mark and drill (optionally tap or install heatset inserts) the top of your left (or right) motor hold bracket for 2 M3 screws use M3 hardware to loosely mount the…
One 80mm fan to cool the boards instead of two 40mm fans. Makes it way quieter and pushes more air.
Currently working on building my Duender. Found this base case, but was planning on using a Octopus V1.1, so I remixed this to fit. It should still work with @The_Creator_2380541 original spacer. You'll need Ruthex M3 Voron heat inserts…
The 4040 Extrusion X Mount should be printed with ABS or ASA (I suppose most filament should be fine) 40% infill 4 walls 0.2mm layer height 0.4mm extrusion width 5 top / bottom layer (Aka Standard Voron Settings) Important Note on the…
The Duender SB Mount Plate should be printed with ABS or ASA (I suppose most filaments should be fine) 40% infill 4 walls 0.2mm layer height 0.4mm extrusion width 5 top / bottom layer (Aka Standard Voron Settings) Requires 9x Voron…
I highly advise you print in petg or abs at 100% infill to avoid instability
If you find yourself wanting to build a Duender with MGN9 rails and 4040 y extrusions, but instead of running the MGN9 y rails in the inner v-slot you need them to run in the outer v-slot, these mounts are for you. Build the frame as per…
This project contains a re-design of the motor mounts from Andizzle, however adds 8mm to the deck height to make them compatible with the MGN9 Duender project. Redesign outer shape to provide better access to belts and pulleys. Bolt hole…
This project contains a re-design of the front tensioner housings from Sergei Irbis, and they re-use the stock pulley holder inserts. The main change is that it uses the M5x45 and M5x25 bolts from the Ender 3 (you need to tap your threads…
This is the mod I first started working on. I was looking for options not to have to buy a sheet of aluminum then drill and cut the plates. I used purchased open-build plates for the Z axis, but this doesn't work for the X gantry. I…
This is my version of an AWD DuEnder. The rails are all MGN9. When I get the chance, I will update this description with a parts list of used hardware to assemble, but most everything is an M3 bolt ranging from 5mm up to 35mm. Print…
Made this for the SK3, but should fit most regular sized skr board with the same mounting pattern such as a V1.4 It's a direct remix of the original Ender control board mount, it has the same bolt pattern for the mounting points to the…
There is a gantry plate for an MGN12C and MGN12H linear rail The ABL mount and the fan duct plate are slotted for adjustability. The ABL mount is designed for a CRTouch, unsure if it works with a BLTouch. There is an optional mount for a…
This mod moves X beam 3mm back. had to do that to align the belts to the Stealthchanger shuttle. i build Dueender (DueVyper in my case) not sure if it the same for other printers to keep in mind.
X Mount MGN12 This mod is for Duender MGN9, however it confusingly supports an MGN12 rail on the X axis. Doing this expands the toolhead options as effectively any Voron toolhead will simply fit as-is. I have a StealthBurner on mine, and…
Motor Mounts MGN9 Extended This project takes my previous MGN9 Motor Mounts project and moves everything further back to allow more Y axis travel. You will probably want to have 320mm rails (get 350mm rails and trim 30mm from it with an…
The extrusionless gantry for the duender was already a great idea by Shobei, unfortunately it won't work with the current Version of the Duender, since it needs the grooves for the 2020 Profiles. SlickChris remixed the gantry but there…
I did not like how the original frontmounts looked, so I decided to redesign them. You don't need to change anythig of the original parts, they are “plug and play”, just 2 more m5x8 screws are needed. My 4040 extrusions are about 20mm…
Note that the X limit switch is triggering on the extruder body, it was designed for use with a stealthburner extruder, if you can a different extruder you will need to verify that it triggers on the extruder, and please do so before you…
I had a lot of trouble getting the idler & spacers installed in the belt tensioner for the DuEnder, so I created this jig that makes that process much much simpler. You just set the jig into place, drop in your idler, then put the spacers…
When I was putting my DuEnder together, I wasn't ready to commit to buying rails, but I wanted to have the option to do so later.... I looked through the differences, and the only real issue is the height of the belt path, which shifted…
These are 4040 Extrusion Mounts that are compatible with the changes I made for the Wheeled Hybrid Model below.
This is a carriage mount for the Dragonburner with belt path cutouts that are specifically for a raised version of the DuEnder belt paths This will need the toolhead plate template from the project below to put the slots in the right…
What is this? This is a mod that allows you to use 20-tooth idlers instead of 16-tooth idlers (or flanged bearings) on your Duender. Maybe you have some leftover, maybe you just ordered the wrong ones like me :-D And it replaces the big…
Simple extrusion mounted umbilical + ptfe tube holder for the duender. Use with PUG cable strain relief https://www.printables.com/model/378567-pug-parametric-umbilical-gland
Motivation The Duender belt tensioners are a little fiddly to assemble. The original Ender3 does not include proper belt tensioners, but the V2 does. (And probably later versions as well.) So why not just re-use them instead of creating…
So, you built your Duender from one or more Ender3v2 or later and want to use the slimmer PSU, as well as the split power switch + outlet combo, but you don't want to shock yourself when touching it in the wrong spot? Then you've come to…
The Duender logo by @coldstorm as an STL, so that you can include it in your designs where you see it fit :-) It's centered on the origin, so you should be able to easily place it wherever you want and scale it to size. The original logo…
Uploading this as basically just ideas for another way of doing things. This came to me when I was disassembling the Ender 3 V2 and noticed there was a lot of decent flat sheet metal stock. I happened to have a pair of aviation snips/tin…
Integrated belt tensioners/Medusa HC mount for the Duender and Medusa HC hotend changer by Sergei Irbis. Replaces the stock tensioner from the MGN9H Pins version and the Medusa HC mounting. No more glue!
Integrated belt tensioners/Medusa HC mount for the Duender and Medusa HC hotend changer by Sergei Irbis. Replaces the stock tensioner from the MGN12H Pins version and the Medusa HC mounting. No more glue!
