The clamp for the FINDA probe on the UltiMulti Selector_B19_Experimental.stl part broke when I tried to tighten the screw. I also preferred KuroNeko511's Finda Clamp Mod before I switched to the UltiMulti, so I combined that to the…
This is a Finda cable stress relief. Why another one? Because it is simple, easy to print and easy to install. The LED is still visible. If you want to better see the led print it with a transparent filament. Changes 11.5.2024 oriented…
This model extension was designed to be sure that the FINDA cable will be fixed inside relief channel correctly and will not pop out. Printed from PETG, 100% fill
This is the same chamfered modification but for the R4 version. I also made the chamfer more pronounced.
This thing just clips on top of the Finda on the MMU to give the cable some protection. My printer is in an enclosure with limited space. I made this so that when I move the printer around I don't crush the Finda cable against the…
I wanted to experiment with alternative mountings of the MMU, so I incoorperated a spring to the FINDA ball to exclude the gravity factor. Knife- and tube-fittting holder is slightly modded, and I added the FINDA cable guide. These mods…
I adjusted the geometry of the selector to make the bridge on the window/cavity side a bit easier to print by eliminating a stepped section and adjusting an angle inside the cavity (see photo). I also edited the small area that sometimes…
Just minor modifications and deepened blade slot like the latest prusa design.
La pièce d'origine ne plaquait pas sur le sélecteur Finda. (voir photo). Peut-être que mes lames sont trop épaisses? La découpe des filaments trop avancés dans le MMU fonctionnait mal. En supprimant les bossages, les pièces joignent…
Update 12.04.2022 - added a v2: The Clip is now slightly "bigger" for a better fit on the cable and filament. Please let me know if its still too tight. Just cut a piece off of your filament, print ca. 5 of the Cable clips and mount…
FINDA cable guide for “MMU2S Relocated CCA” For all the upgrades see: https://www.printables.com/model/110448-mmu2s-relocated-cca
I had some problems where the senor wires on my MMU2S would weaken over time through the back and forth movement. So Here is a support for said wire using a piece of 1.75 mm filament to support it. There are two options for mounting the…
I needed a strain relief that was shorter than the original design by goldbird3_87567 . I also noticed there was a supplemental model that kept the cable from falling out. So I made it shorter and changed the cable grove to capture the…
A low profile strain relief for your MMU3 FINDA cable. Comes in two varieties: Strain-relief with straightener feature. See red caption in photo. Can only be used with the FINDA cable routing around the right side of the MMU, which is the…
Improved MMU2 selector with rectangular slot for magnet found in Prusa MK3S/MMU2S kit parts. This is a modification of the E2 version of MMU2 selector mod by emanuvele, inspired by same modification of the previsous V9 version done by…
This is a remix of the MMU2S Selector FINDA version R2 (improved blade holder mentioned in release notes for Firmware 3.9.0) with a slot for a 6x2x10 magnet for improved FINDA reliability. (The magnet used is the smaller of the magnets…
I liked the concept of the original design, but I couldn't get it to print well perhaps because I was less experienced with printing back then. But I did know how to use Solidworks, and after some trial and error, I came up with this…
A small upgrade which protect the FINDA cable on the probe side. (Yes, I did kill original FINDA by being careless.) Print instructions PETG @ 0.2 layers works fine. Update 2022-08-28 Added version with thicker walls. It is a bit stiffer…
Filament Sensor on Base of an optical End Switch instead of a FINDA (Prusa Filament Sensor) for MMU2
Remove FESTO fitting from MMU2S and insert calibration fingers and adjust FINDA sensor position so it is ON for 1.5 mm and 1.75 mm and OFF for 1.25 mm and 1.00 mm. The FINDA has a dim LED on its top, and its status can also be read from…
This is a remix of the original mmu2s selector from prusa. I always had problems with the reliability of the finda sensor in the selector. I first tried the mod with a magnet e.g.…
This is the modified version of the MMU3 selector finda with chamfered filament intake that makes it easy for the filament to slide in. Sometimes, espesially when the filament tip is very flat it hits to the side of the hole on the…
Change the mount clamp part of the original mmu3-selector-finda-R4 and reduce the chance of crack when clamping FINDA. Spare parts: 2 x m3x10 screw, 2 x m3 hex nuts or 2 x m3 square nuts.
Support pour maintenir la courbe du câble de la Sonde Finda du MMu2s 2 vis : 1 M3X10 avec écrou carré 1 M2X18 avec écrou
