I'm assembly a tool in the Stealth changer ecosystem, and i encountered an interference in the original mounting point that i solved with this offset standoffs. You can use this in case your building a tool with: Orbiter v2 Drangon burner…
In my opinion the original bracket is too thin and I didn't feel comfortable with it. So I opened it in Fusion and made it thicker. The Orbitool 2 toolhead board still fits, only the “outside” is edited. I used these settings and printed…
This is a tool board protective base with a fan mount for cooling the Orbitool tool board mounted to a Orbiter2 extruder. I remixed it to support a 4010 fan and the umbilical cable. Printed in ASA 5 walls, bottom and top. Orca 2.2.0 If…
Provides support for O2S Toolboard
In my opinion the original bracket is too thin and I didn't feel comfortable with it. So I opened it in Fusion and made it thicker. The Orbitool 2 toolhead board still fits, only the “outside” is edited. I used these settings and printed…
This is a tool board protective base with a fan mount for cooling the Orbitool tool board mounted to a Orbiter2 extruder. I remixed it to support a 4010 fan and the umbilical cable. Printed in ASA 5 walls, bottom and top. Orca 2.2.0 If…
Remix of the original EBB42 vertical toolboard mount for LDO Orbitool O2 toolboard. It will fit both V-Core4 and V-Core3 toolhead. Instead of a pianowire there is a hole for a piece of nylon filament. The step file is included so it is…
Din mount for the LDO orbitool USB adapter. You will need the original mount from the github https://github.com/RobertLorincz/Orbiter-Toolboards/blob/main/Orbiter%20O2%20Toolboard/3D%20CAD/USB%20Adaptor%20mount.stl
My first desighn (that i publish) :) was lookin every where for eva2.4 for ratrig vcore 3 with goliath watercooled hotend, didnt find:\. so did a little remix to the original eva 2.4. on the way remixed and added orbitool mount, and…
Din Rail mount for the Orbitool 2O's USB Adapter Board. Requires 1x universal Din Rail Adapter from the E3NG Project 1x m3 Heat set Insert 2x M3x6
BOM: M3x35 SHCS Qty:2 M3x10 SHCS Qty:2 M3 Heat set insert Qty:2 (Voron Style 4.5x5mm) No supports needed. Removable support is included in the model. PUG Version needs the above as well as: M3x12 SHCS Qty:1 M4 Heat set insert Qty:1 (Voron…
Adapted the mounting points to align with the Bondtech LGX Lite Pro and XOL Carriage. BOM: - 1x M3x4x5 Heatset (Voron standard) - 1x M3x6 BHCS (Board to mount heatset) - 2x 20mm M3 Standoffs - 2x M3x12 BHCS (Mount/board to standoffs) - 2x…
This is a remix of the LDO O2S WirerestrainBody for mounting the Orbitool O2S toolboard on the RatRig V-Core 4. The original LDO model interferes with the endstop PCB and fan grill on the VC4 toolhead, preventing proper mounting. This…
Hello! Here is my version of a toolboard mount for the Orbitool O2S on the stock RatRig VCore 4 toolhead. Since the endstop is in the way of the lower mounting standoff, I did not use it, only the top hole of the toolboard has a more…
Modified the Orbitool O2S USB Adapter so that it can be attached to a standard Voron din clip with M2x10 self tapping screws.
Mount for orbitool o2s meant to be paired with Ratrig V-core 4.Mount for orbitool o2s meant to be paired with Ratrig V-core 4. At this point I have it working with both standoffs using modified X endstop mount. It can be used with only…
This model has been made with the intention to keep everything from the original rrtoolhead and to avoid non-rigid mount. it use 3 point for the fixation. some features : Lightweight and rigid - 3 fixation point xendstop compatible a cap…
Need a better strain relief? Use this one! Includes mounting holes for a 4010 fan when used with standard M3 standoffs. Simply sandwich this between your Orbiter and O2S. Easy access to boot/reset buttons, cutouts for filament sensor…
This is a cover that i made for the Orbitool O2 toolboard. You can use a 40x40 fan or the fanguard. The holls you need to drill and tap then, they are m3. I printed them in PLA+ and still holding strong.
Adapted the original one from Cristian I: Adaption of the original one from Cristian I: https://www.printables.com/model/1388826-orbitool-o2s-toolboard-mount-for-the-ratrig-vc4-to Kudos to Christian!
This model was designed to work with the Orbitool 02 board and the Stealth Charger for the Dragon Burner
Provides support for O2S Toolboard
For use in high-temperature printing chambers or higher extruder motor currents on Orbitool O2S. The fan power can be split from the hotend cooling fan port, cimp each pair of wires into one crimping sleeve. Following parts required: 1x…
This model modifies the VORON Trident DIN rail mount for use with Robert Lorincz's USB adapter PCB. Use an M3x8 or M3x10 self tapping or machine screw to screw the PCB to the mount. The thickness of the DIN rail mount has also been…
For cable restraint you will need to download and print O2S Wirestrain_Lock.stl Has a hole on the top for piano wire.
I have been using this on my Voron 2.4 printer for over 300 hours now and it's going great! One small problem is I accidentally broke off the reset button and had to improvise when flashing it. It's possible putting it into the mount…
