XY Linear Guide (Compliant Mechanism)
We calculate the final price from your selected file. You review and accept it before payment.
Saved on this device.
This simple compliant mechanism allows you to guide the movement of an object.
- Rating
- 4.8 / 5
- Likes
- 86
- Downloads
- 261
- Makes
- 7
- Views
- 3,522
- Reviews
- 5
Updated at source:
Model information
- Source
- Printables
- Category
- Engineering
- License
- Creative Commons — Attribution — Noncommercial — Share Alike
Hello,
this is a simple XY linear guide which allows you to move an object
10 mm in X
and
approx. 7.5 mm in Y
It doesn't matter how many times you use the mechanism, as the material is only ever deformed in the elastic region, it will always return to its original position.
The mechanism consists of a single component and can be printed in about 45 minutes.
I may reduce the movement in Y by adding two stops in the future. If that is the case, I will upload the updated version.
I hope you like it. If it does not work for you please leave a comment or shoot me a message instead of just posting a 1 star review, I'm sure there is no problem that can't be solved.
