This is a remix of this model:
https://www.printables.com/model/139183-ender-3-v2-voron-stealthburner-conversion
Important: You have to flip the bottom bolt of you original Ender 3 Carriage, so that your screw head is on the printhead side, and the nut is on the opposing side, otherwise you WILL damage your Probe. Ask me how I know.
Hardware needed:
- 8x Heatset insert Voron Spec
- 2x M3x20 DIN912 CRTouch Mounting
- 5x M3x10 DIN912
- 2x M3x16 DIN912
Print using Voron Settings:
0.2 layers, 4 perimeters, 5 top/bottom layers
Depending on your choice of hotend you might need to change the height of the spacer, the 20mm one worked as intended, for a Bambu Hotend. You can change the height of the spacer with a non-uniform scale in your slicer, or edit in CAD.
I added F3D and Step files, if you need anything else just contact me.
Important: You have to flip the bottom bolt of you original Ender 3 Carriage, so that your screw head is on the printhead side, and the nut is on the opposing side, otherwise you WILL damage your Probe. Ask me how I know.
The CRTouch Model in my CAD files is from here:
https://grabcad.com/library/cr-touch-dummy-1
Stealthburner by Vorondesign:
https://github.com/VoronDesign/Voron-Stealthburner/tree/main/CAD
