The Fosi Audio V3 Mono is an incredible piece of engineering, but it uses its entire aluminum chassis to dissipate heat. When sitting flat on a desk or stacked, airflow to the bottom of the unit is restricted. This stand helps solve the…
I have a massage table and mounted transducers to the bottom of it to make a sound bed. I needed a holder for my Fosi Audio TP-02 subwoofer amplifier to hold it on the side of the table. Obviously, there were no designs this specific, so…
All parts snapfit really hard together using slight force opon a flat surface. I even used a small hammer while doing it. Maybe use some sanding or deburring tool to make fit. Once parts are fitted together they stay together firmly. On…
Mount for the Fosi Audio TB10A/TPA3116 that is compatible with the LEGO Computer Stream Deck Mount (from EMN ) Please note this is a quite tight fit and will require to remove the “non-slipping” pads under the Audio controler. I did put…
The Fosi Audio V3 Mono is an incredible piece of engineering, but it uses its entire aluminum chassis to dissipate heat. When sitting flat on a desk or stacked, airflow to the bottom of the unit is restricted. This stand helps solve the…
Just a simple model to mount the TB10D under the desk. I wanted a simple solution to mount it under my desk without blocking any port. I printed it in a Creality K1, using black PLA matte, with 0.30mm layer height, and using simple tree…
A small box that sits under the Fosi V3 Mono and hides inside a 120mm fan which cools down the amp. Running at 50% its inaudible and keeps the amp stone cold. Prints in two parts without supports.
Remix to adapt the model for the TB10D to fit the TB10A. Power brick is identical, so no change to that model.
You just need to print the piece in the orientation it's in. You'll have to remove the four rubber feet from the Fosi Audio K5 Pro, and once everything is in place, stick some double-sided tape on the top for a good grip. This way, we…
It is preferable to print with support for better result.
Model for under desk mounting the FOSI v3 amp using double sided tape. That leaves a bit of breathing room on top. Missed the oversized front lip, which ended up sitting flush on the front face. Setup to put the knob level with a directly…
This is a simple, snug-fit under-desk mount I made for my Fosi Audio DS2 headphone amplifier. It has large breathing holes to enable access to the buttons and allow viewing the LED, but also to allow the metal chassis of the device to…
I needed a compact and efficient way to organize four mono amps for a DIY speaker system upgrade, so I designed this enclosure to house two of the amps along with a 120mm fan mounted at the bottom. In my setup, I'm using the…
This model uses all four stock standoffs as attachment points. This makes a pretty snug fit. It also offers some thin vents on both sides for air circulation. You don't need special parts nor special tools to install this.
a holder to mount the board under a shelf you need 4 screws 3.5 x 12/16 mm
Stand for the Fosi Audio K7 * DAC/AMP. The angle helps to make the display better readable, including a integrated channel to route a cable from the front to the back. There is a closed version, but also a version what is just a frame…
The Fosi v3 Mono can get pretty warm (uncomfortable to touch). The V3s have ventilation ports on the side. These stands will hopefully result in better ventilation. Note though that the ones sitting in the middle of the stack have no cool…
Print two of these laying on the side, get four countersunk screws (I used 4mm ones, 3.5mm would have been a better fit) suitable for the material you're mounting it to, drill if needed, screw it in. Useful if you want the amplifier…
As per title, simple feet extension for Fosi audio ZA3 and ZD3 may fit other Fosi products, but that's the ones I have. I also used used generic felt / silicone pads to prevent scratches. 15mm high, flat or chamfered base to choose from.…
A bracket to mount Fosi DAC under a desk. Holes are made for 3mm screws, either countersunk or button head. Or you could use a double dided sticky tape.
I wanted a way to mount my Fosi Amp to my sim rig and came up with this design. Enjoy! Print Settings Printer Brand: Ultimaker Printer: S5 Supports: Yes Category: Electronics
I wanted to mount the power brick to the side of my sim rig and designed these. Enjoy! Print Settings Printer Brand: Ultimaker Printer: S5 Supports: No Category: Electronics
Amplifier will fit in the mount with the controls facing downward. Printed 0.20 mm layer with PLA and 15% infill.
A simple bracket to mount a Fosi Audio V3 Stereo Amplifier to a 30 series extrusion.
10-inch Rack mount for fosi audio BL20C. Additional images coming soon. Edit: Increased size of cutout by 1.5mm in each direction. Previous hole was slightly too small.
Update to my dual box setup. Now all four Fosi V3 Mono amps are housed in the same box. Why four amps? I use a digital crossover of my DIY speakers (CamillaDSP). In my setup, I use two “audiophile-grade” Noctua NF-A12x25 5V PWM fan,…
I wanted something that would hold my Fosi Audio DS2 headphone amp in place on my iPhone. This worked out very well. It has a slot that exposes the volume buttons on the side. I used this Magsafe ring on the back. They're adhesive so just…
I built a record console and use Fosi Audio components for the Pre-Amp and Amplifier. The amplifier - Fosi Audio T20 - has a large power brick so I made this simple bracket to mount it.
After not finding a fitting Model, I decided to create my own. It is my first created from scratch Model. The parameters in FreeCad might not be completely adjustable, as I do not yet know the best approach for parametric modeling. PS:…
Strong and versatile stand for your mini amps , stackable !! R1: Better footing and base added , enjoy !
This is a Remix of Quad Fosi Audio V3 Mono Box with Fans: https://www.printables.com/model/1448255-quad-fosi-audio-v3-m Thanks to the Original Creator
Please find 2 remix from the great model from statuscomplex. V1 : If you want to screw it, I added screws holes V3 : If you want to glue it with 2 sides tape, I modified the design Model from statuscomplex for under desk mounting the FOSI…
I have a massage table and mounted transducers to the bottom of it to make a sound bed. I needed a holder for my Fosi Audio TP-02 subwoofer amplifier to hold it on the side of the table. Obviously, there were no designs this specific, so…
All parts snapfit really hard together using slight force opon a flat surface. I even used a small hammer while doing it. Maybe use some sanding or deburring tool to make fit. Once parts are fitted together they stay together firmly. On…
Remix of the3droom’s under-counter mount for the Fosi BT30D amplifier, adapted for compatibility with cyb’s Fosi Audio BT30D Pro open housing mod . Features a honeycomb ventilation structure aligned with the enclosure to preserve…
Printed with PLA, 0.2 mm layers, 30 % gyroid infil. Holes are M8 spaced in 20 mm pattern to fit standard aluminium profiles. Use holes 1, 3 and 5 for odd amount of channels on the aluminium profile (4040, 12040) and holes 2 and 4 for even…
I have Fosi Audio DACs and amps in one room, that feed speaker systems in two rooms. I needed a way to keep four of the Fosi power supplies straight. It’s a pretty simple design. 180mm square and a groove under each power supply so that…
This is something i did for my Fosi Audio BL20C AMP to mount under my desk.
Here's a little shelf I put together for my Fosi Bluetooth amp. I printed it with PLA.
I have some Audio Engine A2+ speakers and they're excellent but about a year ago the capacitors or something on the internal DAC started going bad and the right passive speaker was getting quieter and quieter. I was having to…
Mount for the Fosi Audio TB10D amplifier https://www.amazon.com/dp/B08MJBG53V?psc=1&ref=ppx_yo2ov_dt_b_product_det I designed this up quickly to be able to mount these amps on the side of my sim rig to drive some bass transducers /…
Printed in PLA with 15% infill, still plenty strong enough to hold the power supply.
I use some bookshelf speaker on my Desktop connected to a Fosi Audio ZK1002D Mini Amp from Amazon. The Fact that the Amp is so tiny, and it's flying around on my desk annoys me, and I designed a simple solution to mount it under my desk.…
I upgraded my old Logitech Z-5300e 5.1 surround speakers on my computer to the Klipsch Black Reference Theater 5.1 Surround Sound System. However, since these were going on a computer, the 1/8" AUX Audio jacks on the motherboard were not…
NOTE: Tolerances are currently set at 0.25mm on all dimensions, depending on how well your printer is calibrated this may lead to a tight press fit. You may want to print the first ~10 layers to confirm that you don't need to scale the…
Since the thermal design of the amp is exceptionally poor because the heat generating components aren't directly connected to the housing and do not allow the amp to be cooled properly I designed this housing which is designed for the amp…
Simply download and print. Redesigned in Bambu Lab Studio when I printed it on my X1C in BBL PLA.
bonito pez ,altura de capa 0.2 boquilla 4.0 sin soportes filamento pla velocidad 30mm
This is my first 3d model ever. I have several desktop dac/amps that I printed mounts for, but the Fosi k5 I use for gaming was not being shown any love. I used #6-¾" construction/wood screws to mount it to my desk. The front stops behind…
Stojanek na fosilie/kameny --- trilobit/fossil/stone stand
Couldn't find one so designed my own. bom: 2x printed parts 4x woodscrew
Very basic stand specifically designed for pairing a Topping D10s DAC with a Fosi BT30D Class D mini-amp. 140mm X 150mm. Top could be glued to the base if you wish, but sits fine when left loose. Print Settings Printer Brand: Creality…
Fosi V3 mono (not V3 stereo) stand v1.4 Includes: (1) Universal stand (position vertical or horizontal) (1) Vertical only stand -Changelog- Version: 1.4 (03/2025) - Minor design tweaks and even more precise/snug fit. Included a vertical…
Simple TinkerCAD wall mount for the Fosi Audio V3 Mono Power Amplifier. It uses the original rubber feets as fixpoints.
