45 models
This set of files demonstrates a way to make electrical pushbuttons and keypads. It uses conductive filament and PLA. They are formed using a layering of conductive filament and non-conductive PLA. Files included are 3mf and step. There…
A simple bracket that slides into the slots on an Apple II+ or Apple //e and and holds a pushbutton. I included one that fits on the left or right side. I also included the FreeCAD source file as someone could re-use the hooks to mount…
This is as near one to one as I could get to the real OTTO P7-8 switch including switch travel and force however some dimensions were not in the datasheet. this was designed to be printed in resin and is almost guaranteed not work with…
This is as near one to one as I could get to the real OTTO P7-2 switch including switch travel and force however some dimensions were not in the datasheet. this was designed to be printed in resin and is almost guaranteed not work with…
A sound reactive wled enclosure using an esp32 d1 mini. Note that an esp32 is needed for wled sound reactive. parts required: printed top and bottom of the enclosure. print at 80% infill for strength. INMP 441 mems microphone like…
This is pushbutton I made. Inside is 12mm Waterproof 2 PIN Momentary Push Button like this:…
A socket to fasten the ring nut on M22 pushbuttons. Works with ¼ inch ratchets.
I got so tired of panel building and trying to get the nuts tight on lights, pushbuttons & selector switches. I did things the hard way and made prototypes out of aluminum… Then I got a 3d printer… and more people wanted these sockets!…
Handheld push button case. Usage example - Wired Remote Switch for Mark 7 Autoloader or any other application, where handheld push button case is needed. Designed for 19mm push button, for example:…
This holder is designed for use with Dillon 650/750, as it attaches to the case/bullet feeder rod and is intended to hold “ Handheld case for pushbutton ”, published here on PrusaPrinters. The source model is published as well, so you can…
Needed a way to hold a 22mm push button. Modified my 30mm design to fit. I printed in PETG, but it should work in PLA
This is the small actuating piece that goes inside a vintage Philco radio Pushbutton assembly. I have attached the Fusion360 file that I created. The model is parameterized and there a fudge factors that can be used to adjust the model to…
[DE:] Bedienknöpfe für das Multifunktionsinstrument am Tacho des Smart Roadster. Die kleinen, seitlichen Knöpfe müssen zweimal gedruckt werden. Die besten Ergebnisse habe ich mit einer Schichthöhe von 0.1 mm erreicht. Support: ja,…
Has this ever happened to you? You're repairing a child's toy and find that you need to replace a push-button switch. After going through datasheets and measuring up each dimension you find the perfect replacement. A week passes and your…
Pushbuttons for that great guitar! Print pearl white or pearl ivory PETG and polish by hand or ABS and acetone vapor polish it, no supports needed
Here is my attempt at replicating the pushbutton insert for the IBM SYSTEM/360 and System/370 mainframe computers that were popular during the mid-1960s to late 1970s. These machines had operator consoles with numerous switches, lights…
A 1U rack panel for a 19 inch rack. Has mounting holes for 8 square pushbuttons, two LED-s and 2 toggle switches. I made this to have some programmable buttons available in front of the rack, to trigger binary sensors in HomeAssistant. We…
Fits standard 12mm momentary switches easily available from Aliexpress. I used these here, in 12mm, Momentary, Red, 110-220V. They are very low current and you can either wire across the relay terminals if you want the light to be OFF…
I had a hard time removing removing SANWA-OBSF-30 without damaging the tabs by hand. So I modeled this tool to assist in extraction. Consists of a cylinder to press the tabs inward and a plunger to push the button out Should also work for…
This is a tool to help remove 24mm Japanese pushbuttons, like Sanwa OBSF-24 Should also work with other Japanese 24mm buttons, Including OBSJ and OBSC
For my little pneumatic press - built one just because I can - I needed two pushbutton switches, to make sure I won't press my fingers. The base is massive material, so I needed to make something to hold these buttons. It is a two part…
Download the FreeCAD File and adjust the values in the “values” spreadsheet. Export the Body as STL. After printing glue the end switch to the mount as shown in the CAD File. For the V2 version, just click the MX Switch into the hole.
Originally designed this as an emergency stop for my router then printed three more for a school quiz show. Fits standard MX Switches.
Basic stand created to hold a pushbutton board, LCD display, and an Arduino Nano board for my A450 Press. Only the .stl is published - the Fusion 360 file is a mess (was using Fusion for the first time when creating the stand). Printed…
Mount your Push button box on a Standard Wire shelf. For Schneider (or copy) single PB box. May require one or two wraps of electrical tape to ensure it does no spin under any circumstance. For box model: Schneider Electric XALD101H29 Use…
i use the Gira E2 system in my rooms and i wanted to have a glow in the dark rocker for the kids bedroom. So i took out the caliper and designed it in Fusion 360. In my house, i have the “GiraTaster_d” mounted, in the night you can see my…
YouTube video: https://www.youtube.com/watch?v=gnQClMuNEI4 I'm putting this in the public domain, however if you print and sell these, It would help me a lot to get a few dollars donated to my patreon. https://www.patreon.com/RinoaSG I…
realizado en 2 piezas, flexible y rígido, hace la misma función que el original, pero sin desplazamiento del elemento rígido interior, ya que se ha bloqueado su posición con dos pequeñas guías. su instalación es muy sencilla, se retira la…
I made this in OnShape to act as a holder for 4 6x6x3 momentary pushbuttons with the goal of having a Pi Pico inside of it. I printed it at a medium infill and coarse layer height without supports on my Ender 3.
What's this? This is an electronic button design for quiz games. The idea is to build a host button and up to four player buttons and play as shown in the video: https://www.youtube.com/watch?v=L-j9yM4ZkZQ Buttons have an internal battery…
I've been really into fightsticks for a while and finally decided to print a case and hand wire a cheap brook board to get a hitbox/junkbox-esque controller made. My kailh choc switches were taking so long to ship out, so I decided to use…
Miele 6003710 Pushbutton / Taster / Palpeur /Drukknop / pulsante / interruptor for the front panel. No way I'll be paying 20€ for those. Print either with support or “make overhangs printable”. I used black PETG and 0.12mm layer height…
I modified this design a bit to hold a pushbutton instead of a toggle switch. I also added 3d printable craft sticks to use for assembly! I put together an in depth assembly video as well which can be found on youtube here . I have also…
This little gizmo holds a miniature pushbutton switch (see photos) and has magnets on the bottom to enable it to be held firmly on steel/iron metal surfaces. The pushbutton switch used is designed to be panel mounted in a 1/4" (7mm) hole.…
Introduction Most 3d-printed arcade pushbuttons seem to rely a design where the button cap is only held in place by the stem that the switches cross-shaped connector slides into and is held there only by friction. I'm not very fond of…
Best way to print it is upside-down with supports on the build plate enabled. You'll be able to snap them of pretty easily:) The text on the model photo is “1m”, intended for the construction of a timer. You can find the STL file for…
The opening to fit the switch in these models is nominally 3.7 mm but shrinks a little on my machine, presumably elephant's foot. I include the Fusion 360 file which has parameters for length and inner diameter so you can customize to…
I found a Lovato series LM2T 22mm modular input frame and contact, but did not have a push button actuator. This series has been discontinued so purchase was not really an option. This model is a simple replacement for the pushbutton…
I have printed the beautifully designed Waveshare 7" HDMI LCD (H) Case by ywabiko and everything is great except the screen buttons - they are too deep and quite hard to push. So I installed Fusion 360 and made this panel that you can…
This is a wrench to tighten the large plastic nut on an arcade button. It works well with the Big Dome Pushbutton from SparkFun. (I do not know if it will work with other similar buttons from other vendors.) The OpenSCAD file is included…
This is a wrench to tighten the large plastic nut on an arcade button. It works well with the GoldLeaf Pushbuttons from Ultimarc. (I do not know if it will work with other similar buttons from other vendors.) The OpenSCAD file is included…
Pushbutton holder designed for effortless and secure installation of three 8mm push buttons that you can find on Amazon on a panel. This compact enclosure ensures a snug fit for each button, providing stability and preventing unintended…
Here's a spacer for MASSO Touch panel buttons that makes the button easier to press. Especially if you have big fingers. Installation is simple. Open the case, take photo, disconnect wires, remove switch, add spacer, replace switch,…
I have several of these 16mm Rugged Metal Pushbutton - RGB from Adafruit, and wanted to attach several of them directly to a PCB without soldering, such that it could be easily disassembled without needing to desolder 30+ connections.…
The is for the Philco radios Circa 1940's that use the short push button. The knob measures 0.485x0.477x0.65 I designed the slot slightly larger than the shaft and added a ridge inside the slot to hold it firmly on the shaft. This works…
