A replacement jaw/clamp for a wokmate portable work bench (the original Black and Decker Workmate. Best printed with a more flexible filament to prevent the tangs from snapping. I have used PLA versions even with broken tangs as they hold…
Due to the way Fusion works on imported converted meshes, sometimes you get weirdness (and occasionally even impossibility), and this one is a good example of weirdness. It left an incredibly thin layer of excess skin on the top and…
Little TPU feet to replace the old rubber feet of an old Black+Decker workmate. These are the feet in folded position. I lost two and the two remaining are loose so I replaced them with snug fitting TPU feet. I printed in 95A TPU.
Another little mod I bashed together while making my bench dog holder, this caps the open tops of each leg. It always seemed a bit odd that they didn't come with caps, given how many pennies it would have taken to add them. I printed mine…
Print on its side Wall cout 4-6 walls Infill 40-60% Material PETG or ABS/ASA or stronger Enable supports (organic) use support interface for clean support
LIke nearly every owner of a Workmate portable work bench, I've been dealing with broken leg clips since the day after I bought my Workmate. After searching and trying the available stl designs on the popular sites, and having every one…
I inherited a 1975 Black and Decker 79-001 Type 2 Workmate from my father. The feet have long since dry rotted, and the parts are no longer available. These are designed to fit into the same holes, but uses standard hardware store 5/16…
Gedruckt wurde auf einem Prusa MK4S mit 0.4er Düse, PLA. Perimeter hatte ich auf 8 gestellt und erste und letzte Schicht auf 5 damit die Spannbacke eine gewisse Festigkeit erhält.
Summary A friend of mine has a Black and Decker WORKMATE 8" HOBBYCRAFTER (no 79-025) vise that was missing one of the plastic clamps. He asked if I could 3D print a replacement. I couldn't find any already existing online, so after…
Black & dekker workmate foot. My original foot was broken and one lost so made some new one's in TPU. Work mate spring: https://www.printables.com/model/161518-work-mate-spring Check also my other designs:…
Please read to the very end - an dont forget to leave a like ! These inserts are made to adapt machines without an machine base to a workmate workbench, which are really helpful devices. I use a wooden plate where underneath 4 round…
The crank on my old Workmate broke and needed replacement. I found a really sturdy and well-designed model, but it didn't fit my work bench. So I modified it to fit a shorter shaft. And since the handle on my crank also broke, I designed…
I received the original Black & Decker Workmate years ago as a Christmas gift. To my disappointment one of the crank handles was mis-formed during the molding process and would constantly slip out during use. I got the Workmate out…
A replacement jaw/clamp for a wokmate portable work bench (the original Black and Decker Workmate. Best printed with a more flexible filament to prevent the tangs from snapping. I have used PLA versions even with broken tangs as they hold…
Due to the way Fusion works on imported converted meshes, sometimes you get weirdness (and occasionally even impossibility), and this one is a good example of weirdness. It left an incredibly thin layer of excess skin on the top and…
This is a replacement for the foot cap of the Black & Decker workmate. I have a very old workmate which used to belong to my grandfather, which I am using and maintaining as a very useful memento. It fits many of the Workmate models…
The Workmate has endless durability. Except for it's rubber feet which often go missing or become damaged. With this model you can print new ones! It is not an exact match but fits close enough. It is designed to be printed in TPU though,…
Black & Decker's Workmate Power Tool Table is a “Vintage Item” now, hahaha, I still have mine and it's still perfect apart from needing an offset hole. I originally had a Black & Decker router, but that was truly terrible so I picked up a…
This is a reverse-engineered copy of the leg catch on my Black & Decker Workmate; it was a tricky one to draw! My Workmate has no identity markings but I bought it new in 1981/1982, and from recent research, I believe it to be a WM625…
This foot is for the low height of my dual height workmate. My workmate has no identity markings but I bought it new in 1981/1982, and from recent research, I believe it to be a WM625 E07Z. In about 1996 I had to replace the low-height…
This is a vacuum attachment for the Black & Decker Workmate workbench, but it should be compatible with any workbench or MFT featuring 20mm holes. It features a wide, flat nozzle designed to suction sawdust, cutting debris, and sanding…
Use a 3mm heat insert or nut to attach the handle to the crank. Added a hole in the crank and changed the diameter to fit the 425 model Added a cap to the handle You will need a 3mm (25-40mm) bolt Printed in PETG Carbon Fiber for strength…
Little TPU feet to replace the old rubber feet of an old Black+Decker workmate. These are the feet in folded position. I lost two and the two remaining are loose so I replaced them with snug fitting TPU feet. I printed in 95A TPU.
I've started something of a "make nicer" campaign in my garage, and this is January's.. victim. I have a pair of older Black and Decker Workmate 300 series mini workbenches. I've long since lost all the bench dogs for them, so I've…
Another little mod I bashed together while making my bench dog holder, this caps the open tops of each leg. It always seemed a bit odd that they didn't come with caps, given how many pennies it would have taken to add them. I printed mine…
I lost two feet on my workmate, replaced them by this TPU alternative. They are a little higher and tighter fitting to prevent them from falling off like the originals. There is a hole to fit a self tapping screw but it was not necessary…
Print on its side Wall cout 4-6 walls Infill 40-60% Material PETG or ABS/ASA or stronger Enable supports (organic) use support interface for clean support
The handle on my old Black and Decker Workmate 225 broke, so I made a new one. I used 30% infill and 3 perimeters on the arm. I use 10% infill with a raft on the knob. I used a 1-1/2" - 1/4"-20 hex bolt to attach the knob to the arm. I…
Due to regular usage of my Workmate 2000 the endcaps (rubber feet) gets hollow (see white circle). I want to have new one, but made of standard components. So I designed an endcap with a nut inside for the usage of a standard M8 leveling…
I made this model from scratch for my father-in-law, who broke his blocks and needed replacements. I've tried to track dimensions as best as it is possible. I'm not using the print, but my father-in-law was very happy with the results and…
I needed extended , Threaded .Hold down Dogs .With Spacers . Print Settings Printer Brand: Creality Printer: Ender 3 Rafts: No Supports: No Resolution: .4 Infill: 40% extra infill walls Filament: cant remember PLA red Category: DIY
Portable workmate / workbench foot pad replacement. Fits on 30x30mm square tube legs. Mine have an angle of 12 degr to the floor and are cut off at 5 degr, so that's embedded in the model Print with ABS and a decent wall thickness and…
Replacement crank and handle for cheap workmate / workbench. Fits on 10mm steel shaft, mine was equiped with a 5mm securing hole. (drill hole yourself in model if necessary) Standard M5 bolt fits into handle. Print prefferable in ABS with…
Quick sketch up of a replacement handle for my cheap workmate like workbench handle after jigsawing through the original one. It needs a strong push to click it into place. Print Settings Rafts: Doesn't Matter Supports: Yes Resolution: .2…
My design to replace a broken vice peg for a B&D Workmate workbench has to be better then the original. So I added a 4 position offset standard (0), 2.5, 5 and 10 mm. Also incorporated the hexagon in the centre. You can use this to put…
I made this to spring to replace the broken springs on my folding workbench. I printed them in ABS, but I would think PLA would work fine. I printed them laying on their side. Use a hammer to knock the pin out to remove the broken…
Short, normal, and tall bench dogs for a workmate table Hole is for an m5 threaded insert to pull it out if its stuck
Replacements for B&D Workmates (old, Europe) Two sorts of claws, one needs a bit support on the round part and has the disadvantage that the clamping face is not sligthly tilted (as the originals are). I did not found it slipping on wood…
I inherited a Workmate with all four leg springs broken. Looking to replace them I found the model by @noncorporealb_428881 which is precise in dimensions. I took it as a template to make a more printer friendly version that needs less…
A bracket for holding model rockets on a Black & Decker Workmate. The pegs on the bottom fit the holes in the Workmate so you can compress it slightly and hold the brackets in place. A 3 inch long piece of 3/4" wide self-adhesive…
Replacement foot for Black & Decker Workmate 301. Tight fit to ensure it doesn't slip off - can be pushed on or a couple of hits with a rubber mallet will nicely seat it. Printed in PLA with 20% infill and 0.2 layer height. Printed with a…
My workmate is very practical, but sometimes I just need a larger flat area to work on in my garage. So I took a rest of a wooden board, and attached two of these mounts so I can fix it firmly on top of the workbench. Only additional…
I designed a replacement peg for my BLACK and DECKER Workmate portable workbench. The original part works just fine, however, I needed a few more as several have gone missing over the years. I tried to remain true to the original design…
Can be printed without supports i printed in prusament pccf and needed 100,5% for a snug fit sou you might want to scale it depending on your filament. the shaft might need some sanding for a perfect fit. PLA should be good to. i know…
Simple plastic nut to hold table in position, designed an equivalent to replace the one that was lost. This spins on to the 5/16 bolt to hold the table in place. Print it in place no tapping is nessesary as the threads are printed in and…
Printed in two interlocking parts to make printing easier. When assembling, the parts need to be firmly pushed the last 1mm to lock them into place. Minimal supports on the build plate required for the small part printed with cross…
After watching a restoration video by Hand Tool Rescue of a fractal vise ( https://youtu.be/QBeOgGt\_oWU ), I was fascinated by the mechanism, it lets you clamp curved or irregular objects. I didn't find anything similar when I searched…
A hook and spacer can be attached with 2 screws each.
I designed this holder to keep the bench dogs with my workmate without them getting lost or being stuffed in a drawer somewhere when I need them. It attached to the frame with two zip ties and is out of the way when stored as well as when…
This was an impossible-to-find clip that held together a folding plastic saw horse in the collapsed position. I made several versions. Since the original clips broke I made a few optional ways to use it. A PETG version works but the clips…
Sometimes imitated, and often battered, the Black and Decker Workmate is an invaluable asset found adorning the walls of sheds of handy people from sea to shining sea. Whether its the time-proven design or the familiar orange and black…
Pivot nut for Black & Decker WorkMate work table purchased new work table but somehow nuts included was wrong thread direction RMA case 100% not wasting time found stl & modified to fit 11mm screw with left thread
Large lower foot and smaller triangular foot for Black and Decker Workmate WM5XX. These fit well and have been on mine for some time now. I printed these in Rigid Ink TPU with the speed slowed to about 20mm/sec. I still get a bit of…
When the handle of the Black & Decker Workmate breaks it is easily replaced with this model. I've used it for some time now and it works fine. It's probably not a good idea to print it with regular PLA. I've used Polymax PLA which is very…
When the clamp of the Black & Decker Workmate breaks it is easily replaced with this model. I've used it for some time now and it works fine. It's probably not a good idea to print it with regular PLA. I've used Polymax PLA which is very…
My Black & Decker Workmate peg’s clips had broken so this is a remix of the model from Joel C which he kindly supplied the .step file so I could resize it. This model is resized to fit the later larger Black & Decker Workmate peg with a…
The knob fits a handle with a hole that is 13,5mm and the handel can be 21 mm thick. Printed on a Prusa XL 0.25 structural profile 15% infill Need to be a bit careful when inserting the knob in the handle not to break the flexible ends
Bei den neueren Workmates werden sogar die Kunststoffteile eingespart: Der scharfkante Hebel zum Ver/entriegeln hatte früher eine Schutzkappe - Hier meine Version zum Nachrüsten. In gelb die Version für Stanley, orange für Black&Decker.…
Black & Decker Workmate WM550 Type 9 4 Loch Halter für Spannbacken. Wird gesteckt, verschrauben nicht nötig. Der Halter sollte sich stramm aufstecken lassen und dann einrasten. Filament PETG Flashforce PETG Black
Black & Decker Workmate WM550 Type 9 1 Loch Halter für Spannbacken. Wird gesteckt, verschrauben nicht nötig. Der Halter sollte sich stramm aufstecken lassen und dann einrasten. Filament PETG Flashforce PETG Black
Black&Decker Workmate WM825 - Stanley Deluxe 4 Loch Halter für Spannbacken. Wird gesteckt, verschrauben nicht nötig. Der Halter sollte sich stramm aufstecken lassen und dann einrasten. Filament PETG Flashforce PETG Black
