Mit dem FoamCutter und ein Dremel lassen sich perfekt selber gemachte Werkzeugeinlagen herstellen. Damit bekommt ihr schnell, einfach und genau den Boden bei eurer Werkzeugeinlage herausgetrennt. Wenn euch meine Arbeit gefällt, würde ich…
This electronics box will allow you to add a 2 or 3rd MCU to your DuEnder. It is compatible with both the single or my double MCU box. I have not printed it myself yet so if there are any errors please let me know.
This is a modular coffee organizing unit, based on the idea that you can expand (or subtract) available coffee gear on your workspace. But who are you kidding? When was the last time you subtracted coffee gear from your house, you…
After some overheating issues — probably caused because I live in a very sunny country — I made this fan mount for an 80mm fan. filament = ASA allso It has holes for screws
Stand and base for Nodemcu for easy prototyping and to keep it insulated.
had a few extra screw holes free on my BMCU after mounting it to my A1 Mini, so thought I'd make a little Hydrometer holder. It uses two of the screws that come with the BMCU (M3x25mm IIRC), and should work with all the variants of the…
Check out the original creator’s model for more info and the source design.
I designed this due to not finding a fitting case for my last Project. It has a cable outlet with a 16mm thread for a cable gland and a hole for the usb-c port. The NodeMCU-Esp32S is supposed to fit from above, stands on two little towers…
A mount that uses the original motherboard mounting holes. It has 4 holes that take M3 heat set inserts for screwing the BTT SKT 1.4 into. I remember the fitment not being perfect but I was still able to get it to work. I followed this…
Printed in PETG on heavily modified ender3v2 using klipper.
Nodemcu ESP32-C3 SuperMini WiFi Bluetooth 5.0 USB-C Case with Pins // Remix: Less filament usage & better fit with bad 3d printers
https://makerworld.com/es/models/2583831-case-for-nodemcu-lolin-v3-and-max7219-led-display Este modelo es un remake (remix) de la popular carcasa diseñada originalmente para el Wemos D1 Mini, ahora adaptado para alojar cómodamente un…
Qidi Q2 puts its AP (Host MCU) Board on the left side panel in the chamber. This leads to the chances of the system crash(unexpected shutdown) due to the high temperature of the chamber. General speaking, comsumer grade MCUs have -40°C ~…
This is a case for the NodeMCU ESP-32S development board by Ai-Thinker that can be mounted on an Ikea Skadis pegboard . It uses Skadis T-Nuts for secure and easy installation. Note: This was made for the Micro USB version of the board and…
About: Remix of Multisensor ESP32-WROOM-32 NodeMCU ESPresense by teaser : Added camera hole (10mm hole) Expanded area for extended builtin wifi antenna on modern nodemcu boards that protrudes outside of the dev board Wider hole to connect…
This project contains a box to hide the nodeMCU esp8266 together with a 0.96" oled display. The box is then connected to an external usb power supply that is on the nodeMCU board. First, the nodeMCU board is slid into the bottom box on…
I create my own model to store my ESP-2686 McUs, specifically the NodeMcu V3 variant.
Mit dem FoamCutter und ein Dremel lassen sich perfekt selber gemachte Werkzeugeinlagen herstellen. Damit bekommt ihr schnell, einfach und genau den Boden bei eurer Werkzeugeinlage herausgetrennt. Wenn euch meine Arbeit gefällt, würde ich…
With the addition of a 40mm fan and suitable power supply you can cool your MCU when using the enclosure. You will need to flip the outer panel so the handle socket is at the bottom. If you use the handles, this solution will not work…
This is a case hosting a NodeMCU and a double relay board. This is a slightly changed version of the original case, because the pins for the microcontroller didn't exactly fit my own version, so I created a modified version with adjusted…
This is my attempt at creating an enclosed box for the ESP Development Board 8266 for my LED projects. I wanted to house the board its self along with wago connectors that I have all in one place looking neat and tidy. Wagos are great,…
Designed for 92mm Younuon fan – hole is 93.6x93.6mm As for mounting holes – there are 2 versions: younuon version vs universal version Also there's a simple version without perforation (with younuon and universal mounting holes as well):
A small inconspicuous case for a ESP8266 NodeMCU Development Board v2. Could be used in conjuction with a TTL IR transceiver-head to read Smart-Meters. For the IR transceiver head you could build your own or just buy a cheap one from…
This box was designed to contain a NodeMCU board and a breakout sensor boar. In my case I'm using a DS18b20 sensor to measure room temperature. There is a small space dedicated to the sensor to minimize the thermal effect due to the board…
Enclosure for a NodeMCU ESP8266 board. Allows space for connections onto the male header, with a small cable exit. Also allows access to the USB port. Use two short M2.5 countersunk screws to hold the lid in place. This also clamps the…
A custom box with a sliding lid to house a Node-MCU 30Pin ESP32 board as well as a Meanwell LRS-50watt-5amp. Have included the finished box as well as seperate bases for the individual components. The box should be adjustable via user…
This project uses the CJMCU AS3935 sensor to detect the electromagnetic field of lightning by calculating its strength and distance. Once it captures the lightning, it uploads it to my own meteorology API and also displays the information…
Basic protective box for NodeMcu Base Ver 1.0 Created with OpenScad and YAPP_Box . Scad file attached.
Modified power inlet plate allowing the use of two “LDO style” (IEC 320 C14) power switches. Why? To allow powering the bed and heater separately from the rest of the electronics to better facilitate UPS battery backup. If you do this,…
Simple clone of LimCube 2x2 Transform Pyraminx - Octahedron II . Made this 5 years ago, but uploaded now at the request of a redditor. Note: No center caps are present. Requires some M3 screws.
A minimalist housing design for OpenDTU, providing component visibility and accessibility for maintenance Additional components: 1,3 Zoll OLED display ESP32 NodeMCU NRF24L01+
Doomcube center skirt remix with single power input
Warning: You won't be able to access the Micro USB port with this enclosure! I modified this housing to be quite a bit slimmer, but it still has enough space for a level shifter and a 24V to 5V step down module. That's why the opening for…
Discussion A replacement mainboard cover for the Qidi Plus4 that allows for the use of an 80x25mm fan This is a variant of my other honeycomb design posted on Thingiverse This variant positions the fan more centrally over the hottest…
Remix of the existing bottom-plate/cover of the excellent Space Mushroom Controller horizontal base. I've added a cutout big enough for most USB plugs and a mounting for the board which lets the USB port protrude into the housing, it's…
An ESP8266/NodeMCU enclosure incl a JST connector for a LED strip, a barrel connector for DC power and 4 dupont connectors. Used this for the other part of the dupont connector:…
Portable Moisture Sensor Pen Release v1.3 Parts needed: ESP NodeMCU 8266 with built in screen Moisture Sensor (even though this is a link to a v2.0 Sensor, i have tested it with a multimeter and checked that it works completely as…
This is the original back cover of the QIDI Q1 Pro but with slightly more cooling possibilities on its back.
Use this cover for the QIDI Q1 Pro back cover and use a 3030 fan instead of the small mini fan to get a better cooling for your MCU. Its possible to print it with filament printers but i would probably use a resin printer instead.
mcu board used mainly in building custom keyboards. USB port and pin locations are accurate, the resistor, chip and diodes are for cosmetic purposes only.
Every time I build a little electronics project, I hate how the components usually just rattle around in the case. So I designed this customizeable solution in OpenSCAD that lets me configure the number of pins, the sizing and spacing,…
Designed for modeling, not printing. It's not perfect, but super-duper close for modeling purposes to make a case. Modeled off one of these: https://www.aliexpress.us/item/3256803568851371.html?gatewayAdapt=glo2usa4itemAdapt
If the ESP is used separately and it is necessary to protect the board from possible contact.
Remixed to fit my Voron 2.4 250 mm with 2x TMC5160T Plus and Manta M8P V2.0 board.
Controller Board Mounting Fix The controller board is mounted on the left side using a hexagonal support with threaded holes, into which brass M3 standoffs are screwed. The top of this support is also screwed into the frame. However, I…
Magnetic clipping Doomcube V2 top/bottom panel attachment that allows for panel installation after frame assembly. STLs already in print orientation. there is a 3.25mm bridge for the upper clips but should not require supports. Uses 32…
a minimalist case for node mcu esp8266 un support minimalist pour nodemcu esp8266 soporte minimalista para nodemcu esp8266
I'm making a project that uses these 8x8 RGB LED matricies and I needed a reference model. I couldn't find one so I knocked this one up in OpenScad. Seeing as I couldn't find one here, I figured I'd upload it so anyone can use it as a…
Another remix for the electronics box. Most of us have spare MCU laying around. This box holds 2 Ender 3 MCU ( or same hole pattern) allowing you to designate the 2nd one in Klipper and use it for the Z access control. Doing so will allow…
The model prints in about an hour and a half. You'll need 4x 1mm screws about 4mm long. The holes might need some drilling to fit. Print settings: Layer Height: ~0.2mm Supports: Linear Material: PLA has been tested, but any should work…
Simple 120mm fan cover grill with snap-in removable Venturi. More Venturi design to come :)
A simple model to cover the controller on a Corne keyboard. I use the Corne HiPro Case by mburrows for my Corne keyboards. I don’t have an OLED though so I’ve been using the MCU cover from the Corne Choc Low Profile Case . Problem is that…
This custom-designed NodeMCU/ESP8266 case provides a snug and secure fit for your microcontroller. Featuring a snap-fit design , it requires no screws or glue and offers easy access to boot and reset pins . The case is ventilated to keep…
This electronics box will allow you to add a 2 or 3rd MCU to your DuEnder. It is compatible with both the single or my double MCU box. I have not printed it myself yet so if there are any errors please let me know.
A simple case for the NodeMCU v3 or ESP8266 board – no screws required! With side-mounted screw holes, you can easily attach the case to anything you want. Ein einfaches Gehäuse für das NodeMCU v3 oder ESP8266 Board – ohne Schrauben ! Mit…
Case for MAX7219. This is a remix that accepts an ESP8266 NodeMCU style chip.
This is a modular coffee organizing unit, based on the idea that you can expand (or subtract) available coffee gear on your workspace. But who are you kidding? When was the last time you subtracted coffee gear from your house, you…
ESP32 enclosure with hinged lid. Two sizes - larger allows for dupont wire connections.
Created a Circuit box with 3010 fan and a open lower sections. A lid of same size with a hinge will make it a complete box. it have air vent too for air entry and exit. It is used to keep a ac to dc circuit, nodemcu circuit and a relay…
Small and thin case for NodeMCU ESP8266 that has a removable top, well-fitting micro USB port and a good fit for the board itself. The cover can be clean or have a WiFi logo cutout. ❗You must desolder the pin headers for proper fit. Tip:…
Description from original author's post: Wall-mounted weather station with louvers, includings pins for NodeMCU and louvered pipe for BME280 sensor, strain relief for cable. Pipe ensures distance of about 10 cm between sensor and ESP8266…
This model will allow you to use the BTT 3 EZ in your CR-30, using the stock board mounts. You will not be able to reach the SD Card through the front opening, so you will have to upload via a WebUI like Mainsail or Octoprint.…
This is a case for a 32 x 8 LED matrix and an ESP8266 MCU. It runs on 5V (USB). I've made a connected clock with it. Its purpose is obviously a matter of the software running on the MCU. You'll need to compile, upload a program to the…
Voron 2.4r2 BTT Octopus V1.1 MCU Jig Heres my Jig to the base plate for the MCU CF ABS 260'c 100'c 50mm 45 mins Category: 3D Printer Parts
Motivation For tests with ESP32 NodeMCU and sensors a simple housing with snap-on-lid helps to protect the electronics. Print Printed with PETG housing (Prusa Mango Yellow) lid (Prusa Transparent) plungers (Prusa Transparent Red) → use…
This is a replacement shield for the MCU box of the Sovol SV06 ACE and SV06 Plus ACE printers. (This model is essentially a companion build to the PSU shield .) While the MCU box is not the worst offender in terms of acoustics (that honor…
Use with M3x45 screws and Voron standard heat inserts (3x4x5)
This is a minimalist keychain featuring the iconic Sentry logo from the Marvel Cinematic Universe (MCU). Designed for fans of the powerful yet enigmatic character, this keychain is perfect for backpacks, keys, or as a collectible display…
A bold and clean design of the Sentry logo from the Marvel Cinematic Universe – now as a fridge magnet! This minimalistic, single-color print is perfect for fans of the mysterious and powerful superhero. Add a touch of MCU flair to your…
A remix of Richard Ferringon's SV08 Mainboard cooling plate. Modified to be easier to print and doesn't require inserts. M4 bolts will grip the plastic directly.
This is the remix of atomic fan holder from Filip Luchianenco. I reduced weight and added possibility to attach toolhead mcu 3010 fan. Additionally, I created from scratch mcu fan cover. Printed with ABS, 0.2 layer height. BOM: YOUNUON…
Motherboard box for both the SV06 (Plus) motherboard and a Raspbery Pi 3b / 4b. Relocated the mounting holes so it's more friendly with custom part cooling fans (especially dual 5015)
Modified the under extrusion bearing version to make it flat to fit Doomcube that uses MrNateTheGreats deck panel mount. 2xF695 + M5x12mm BHSC
A remix of Sascha4532's excellent r600 wheel, split into two parts to allow for re-printing of the tyre as and when it wears out. The main wheel body can be printed in PETG or PLA, and the tyre was printed in TPU. You can use m5 bolts to…
A snap-on case for a NodeMCU v3 that has slots for USB charging and sensor wires. Designed to fit DuPont connectors attached to the NodeMCU's pins. This was my first basic case for my DIY Home Assistant setup. I use it hold SHT3x-D…
Sharing an edited version of GEIST's Klor Konrad keyboard case for my personal Klor choc build with keywell adapters. Keywell adapters by github.com/Rookwork/Voyager-keywell-adapters Choc pcb version of the Klor made by…
This is a case for the NodeMCU – ESP32. ⚠ Important Compatibility Notes: it fits if the NodeMCU board has mounting holes at each corner of the board (such as the AZ-Delivery ESP32 Dev KitC V2, ESP32-WROOM-32). This case does not fit the…
This is a remix of one of the clamps from the excellent PCB Workstation with Nano Probes , modified to securely hold small PCBs such as the WBR3 or similar microcontrollers in a vertical orientation . It is ideal for debugging,…
After some overheating issues — probably caused because I live in a very sunny country — I made this fan mount for an 80mm fan. filament = ASA allso It has holes for screws
Nodemcu Home Smart home kit box with 2 way relay and ac-dc adapter space. There are two screw holes at the bottom to connect Universal wall mount
ESP8266 node MCU V3 Case from AZ-Delivery with additional space for screws
Simple clock uses connected to Wifi, NTP and TimeZone Parts required NodeMCU v3 board (lolin variant for the size) like this one A dot matrix led like this one M3 15mm long screws Code and instructions are in GitHub here (I'll also add…
I just had D1Mini ESP32 and NodeMCU / ESP32 in NodeMCU format lying around for the gasmeter. So I remixed the original file and made two new versions. I also included more openings for cooling. Print with treesupport enabled! OpenSCAD is…
Printed with ABS for heat resistance (most likely overkill). It's a very snug fit due to shrinking.
an Atmega32U4 CJMCU board in Step format for use in your own designs
This was made with 2 main ideas: use filament scraps and organize all MCUs at a college electronics laboratory using the minimum amount of filament and space. This trays can be stacked easily. For now, I have designed spacers for both…
Case to make a presence sensor with an ESP32 NodeMCU32s and an LD2450 mmWave sensor, the lid also has holes to glue 9x3mm neodymium magnets. The ESP32 and LD2450 should not require any glue and should stay in place once the lid is screwed…
Hi! i spent a while working on this as a halloween costume and thought i would upload it for all of you What You Need: you need four of the “iron spider arm connector” four of the “Iron Spider Arm Bend V2” four of the “Iron Spider Arm Arm…
(English below) Ein klassisches Problem des Prusa XL, insbesondere bei höheren Umgebungstemperaturen oder Verwendung eines Enclosures: Die MCU überhitzt. Ihr Abdeckblech bietet keine Möglichkeit zur Entwärmung, da weder Kühlrippen,…
Creality K1 / K1 Max – Fan Seal Plate (MCU Cooling Improvement) On the original Creality K1 and K1 Max , the stock 6015 MCU cooling fan is mounted on four posts beneath the printer’s bottom plate. This leaves the fan sitting approximately…
This is a project box / enclosure designed to fit the BusBoard Prototype Systems PR1593K circuit board. That particular board is available with or without a matching ABS case -- this is essentially a clone of that ABS case, only with an…
I've designed this case for the NodeMCU V3.2 Arduino ESP8266 (Lolin/Wemos), with a bit of space for a sensor. Print Settings Rafts: Doesn't Matter Supports: No Category: Electronics
