A quick and dirty designed cover for the rear right corner of the PrusaBox. This version comes with holes for cables. You need two 8 x 4 magnets. It looks like this on the left side: It is designed to use with my magnetic cable duct (see…
Small sensor holder for PrusaBox / Printerbox
This model is a variation of Collin Hill's lid design to hold a 4-way relay under the lid. Updated the model to the new version that goes with the Wago Connector. Included the STEP file for adjustments. I used the Elegoo 4-way relay. A…
I love the (Un)original Prusa Drybox by @BramElema . They're clean, functional, and quite beautiful. I don't have an original Prusa enclosure, though. I have the PrusaBox enclosure by PrinterBox . I'm adapting parts in order for the…
Anpassung des Bauteils an den MK4S
When the machines are close to each other, it is not easy to reach the power button, that’s why I decided to deport it on the front of my boxes.
I wanted to be able to open the doors of my new PrusaBox 2 at 270°.
I wanted to be able to open the doors of my new PrusaBox 1 at 270°.
2 magnets 6x3 mm can be added for a better stand with less vibration. Printable upside down without any supports. Used PETG with 15% Gyroid infill.
Luftkanal - 3 Modelle 2 Versionen (alter und neuer Printer frame) ohne Lüfter mit Lüfter 40mm mit Anbaulüfter 45mm Air duct - 3 models 2 versions (old and new printer frame) without fan with fan 40mm with attached fan 45mm…
Cover for the Temerature Control in https://www.prusaprinters.org/de/prints/75281-prusabox-w1219-temperature-control-housing
This is simply a modified lid of the buck converter housing in the Prusa Box enclosure, allows a 4 way relay board to slide in. Obviously some board sizes may vary, but most are of a generic size. Hopefully the photo also helps. I use…
Mount to install Microsoft Live VX2000 or Microsoft LifeCam Cinema in the PrusaBox made by https://www.printer-box.com This mount was created to get the possebility to use “old” Microsoft WebCams togehter with the [Prusa] Box. Needed…
This is a mod made to mount a 6 relay, 4 relay or 2 relay board in the prusa box by printer-box. This is a universal mounting system that allows you to mount any board from lengths 9mm to 105mm. Original file name…
Remixed the remixed remix of another remix ;) PrusaBox version, for the enclosure made by printer-box, with negative volume to create little cuts on the outer circle, so that it does not hit the plexiglass of the enclosure. If you have…
Implementation of a box made of an old paper core from a spool of Prusament. This variant makes it just a couple of millimeters higher that the core itself. The top and bottom part are modeled after prusament flanges, therefore have a…
I saw that Prusa had released the Buddy 3D camera and jumped on the opportunity! My current camera was acting up and this seemed like a wonderful solution. I have a Prusabox from Printer Box (wonderful company makes great enclosures) set…
When you are printing with your PrusaBox is important to maintain cool your einsy and RPi, at the beginning I was using the cooling duct designed by @colin but when I mounted the RPI It was not able to fix in the correct place, so I have…
This is a combination of the original PrusaBox scrap bin and the E3D Nozzle holder from Paul_GD. All credits should go to the people who designed the separate files. I only combined them together. PrusaBox: https://www.printer-box.com/…
this is the version of the MK4 bin that i remixed for the PrusaBox model 1 allowing for the feet to fit and extending the height of the walls to block debris from landing on the z motors. it is not perfect, it is only rev 2 but if someone…
It is easy to mount and use the same screw as the inside spool holder of the Prusabox
Since I dont realy control my printer from the panel, I think the modular control panel of printer-box is to bulky and I opted for the flat control panel. However, I needed to include the PWM module as I prefer the printer to be silent as…
This is a direct replacement/redesign of the stock PrusaBox hinge that allows the front door to swing open 270 degrees. I needed the door of my PrusaBox to swing open fully so I redesigned their stock hinge to allow this and made minor…
Note: Please see my remix https://www.prusaprinters.org/prints/155787-prusabox-enclosure-enlarged-buck-converter-box-wit for an enlarged version of this same design to more easily fit all the wires with the relay in the lid. This is a…
This model is a variation of Collin Hill's lid design to hold a 4 way relay under the lid. When I printed his design, my board was just a bit too wide to fit in the slots, so I modified the design so that on the right side, the relay…
This is a modified coupler for the modular control panel. The switch hole mount size is 19mm x 12.6mm to allow for larger rocker style switch. The holes were designed to fit these rocker switches. https://www.amazon.ca/gp/product/B07Y1GDRQG
This print is designed to allow mounting a Logitech C920 to the PrusaBox rail, without having to take off the mount that comes supplied with the camera. The original mount just slides into a square housing to hold the camera. The housing…
A compact mount for Logitech C920 webcam. You will need a 1/4-20 UNC screw (tripod mount screw) to mount on this holder. The holder uses two screw holes in the front left steel pillar. Added 3 photos of what the C920 sees when mounted.…
This is an enlarged version of https://www.prusaprinters.org/prints/152385-prusabox-enclosure-buck-converter-box-with-wago-ho. When I put all the wires into the original design with the relay and all the GPIO wires, the box was very…
This is a changed design to my original vertical mount for a Logitech C920 which allows mounting the camera without removing the factory mount from the camera. The original mount was vertical which works ok, but it can vibrate a bit when…
I've adapted the Wago holder to be vertical and double its capacity from two 5 wago (221-415), to fit fo 5 wago blocks. This makes it easier to route both 220V and 12V. The elec box is high enough, so there is still space for the cables…
I also designed a hinged version PrusaBox adapter hinged for "MMU2S Buffer (inspired by RMU Buffer)" so that you can also open the side door with minimal effort. I kept the original box hinge design language so that it does not appear…
This is the hinged version of my design PrusaBox adapter for "MMU2S Buffer (inspired by RMU Buffer)" so that you can also open the side door with minimal effort. I kept the original box hinge design language so that it does not appear…
This is a remix of https://www.printables.com/model/155787-prusabox-enclosure-enlarged-buck-converter-box-wit. The changes made were to add a square hole at the back of the case to allow using an external charger for the Raspberry Pi. I…
This is a 2 part adaptor plate than can be screwed to the modular control panels, and then this adapter plate along with the modular control panel is screwed to the Prusa Box so that the control panel is centered on the front of the Prusa…
Eigenschaften| Höhenverstellbar| Klemmung| Stellbereich ca. 15mm| Kompatibel mit dem Stahlplattenhalter unterhalb des Gehäuses (https://www.printables.com/de/model/78667-prusa-box-enclosure-expandable-steel-sheet-holder)| Benötigtes…
This is a quick and dirty designed cover for the rear left corner of the PrusaBox to hide the cables. It is designed to use with my magnetic cable duct (see here…
The standard cable duct of the PrusaBox has two significant disadvantages. First, the click system can damage the isolation or break cables when squeezed (yes, it did happen to me) and second, it doesn't offer enough space in complex…
Corner cover (top rear left) to hide the cables going to the LED lights and the fan for the PrusaBox. Before After Print with rim and 15% infill. You should't need support, if you keep your fan blowing a 100% from layer 3 or so. See…
This an additional cable duct for the right side (short version) of the PrusaBox, which I needed, because I have a second raspberry on the outside of the Prusa Box and a lot of cables from my fire suppression system going in. Important!…
A quick and dirty designed cover for the rear right corner of the PrusaBox. This version comes without holes for cables. You need two 8 x 4 magnets. It is designed to use with my magnetic cable duct (see here…
This an additional cable duct for the right side (rear) of the PrusaBox if you have cables running here. You will need: Five 8x4 or 8x3 magnets (fix them with superglue, if necessary) Print with support. See picture: This cable duct is…
This an additional cable duct for the right side ( front ) of the PrusaBox if you have cables running here. You will need: Four 8x4 or 8x3 magnets (fix them with superglue, if necessary) Print with support. See picture: You can find the…
This a replacement for the original ventilation grid to protect the Einsy motherboard from dust. You can install it even if you have the original grid installed to the inside or outside. You don't have to remove the original grid. Because…
Cable cover with integrated rail and magnets of course. Now you can mount whatever you want and you can change the vertical position in a blink of an eye. Instructions Print with supports ( Important! Take a look at .gcode ). I recommend…
After having my PrusaBox for a few days, I realized bits of filament like to get into the channel. They are made for the stock feet on the printer, and are only 1mm thick. When i get some time, I may redesign to make in 2 pieces to go…
It's a common recommendation leaving the top window (or all doors) open while printing PLA. I don't think that's a good idea. Because PLA also scatters microplastics. Even if it may not be bioreactive, I don't want to have it in my lungs.…
Been looking for the W1219 Temperature Control but delivery time was too long so decided to try another one, so this is my redesign of the modular front housing for the DC12V Digital Temperature controller to fit. Here is the link:…
A colleague need this windows to mount his MMU2S on his prusabox, I made these models using my acrylic windows as a sample. Made left version with and without window for MMU2S data/power cables, the version with window cant be removed…
Redesigned version damper foot to fit next to the Linear rail bracket. The original one been chopped up to fit in first so this is my version if you have linear rail upgrade too should be all good fit.
For this design, I disassembled an AC Infinity T8 and created a top exhaust for the PrusaBox out of its parts. It is essentially based on my first design. If you don't have an AC Infinity T8 or don't want to spent 120 bucks on one just to…
We couldn’t fix the downloadable feet on the Printer - Box site on the back of the Bear frame so I modified them so I could mount them. There were 2 screws to fix each foot on the frame, on the new version there is only one screw per…
Thermometer-Halter für PrusaBox zur stabilen und festen Montage. Ich habe folgendes Thermometer genutzt:…
I have created better back cover of the cables going out of the heatbed used for PRUSA BOX. The original one has unsufficient space inside for the cables to be placed comfortably. My upgrade cover is almost of the same size, but the…
In my case i have not much room behind the printer and most of the air exhaust were to big - so i designed one by myself. Comes greate with the 80mm-Fan on the inside from the official moddingoptions of the PrusaBox. You can screw them…
The multiholder can be used as 5 spools holder either 5 1kg spools or 1pc 2kg and 4pc of 1kg spools or, can be modified (by printing a few diferent parts) to hold 2 kg spools and 3 5kg spools and yet it still fits the roof of Prusa box…
PWM board housing to be used with Prusa Box modular front, allows proportional fan control. Print with buttons face down. You may need to add support to the end with the vent holes - specifically the long 2mm high ridge where the end of…
I updated this to work with a 5inch monitor and Colin Hill's “Prusa Box PWM Temperature & Fan Proportional Speed Control For Modular Front 3D Printer Enclosure”. Before you could not get to all of the screws (Quick_top_remove mod) to…
Remix of wilsondg's remix, changed amount of keystone inserts, one RG6 pass thru and one USB C pass thru, put small switch back. I am going to use the PI 4B and will run it with the USB C factory power supply plugged in the back. Later I…
I like easy, so I fixed the top hole so no drilling to make screw go in easy. I would recommend you also get this: https://www.printables.com/model/353401-prusabox-enclosure-adapter-plate-to-center-modular I fixed it to work with the…
Shortened top to fix a lot better, enlarged cable hole so more cables will fit (fan, leds ...etc).
Added another WAGO holder, so now two 5 connector and two 3 connector. I hooked up 12V and 5 V pos and neg from buck converter for easy power hookup. Also included the lid (…
UPDATE 02.03.2023 Da mir langweilig war habe ich den Luftdurchsatz verbessert indem ich oben noch einen 80mm “Pull”-Lüfter angebracht habe. Die Konstruktion ist etwas komplexer geworden da bei mir auf der Prusabox noch die Filamentboxen…
I was looking for a way to use the expandable sheet holder and still use the modular control panel centering plate. I remixed the bottom control panel covers to relocate the mounting holes so the brackets from the expandable sheet holder…
The only change to this model compared to the original is the lower part of the box. You can use/print the cap, upper half, and tray from the original design.
More room for power supply wires. Enlarged Buck Converter box, RJ45 Network Port, USB C, Small switch No WAGO. You can go here for parts to complete this.…
2024-01-19: Ajout d'une version de la face arrière avec fixation pour le rail des boîtiers de Printer-Box . (absent des photos) Pour la version Wide (grand angle) du RaspiCam V3, je n'ai pas testé avec la version normale (je crois que…
This is an option to mount the WaveShare 5" DSI Display and a PI4 with a X735 shield ( https://geekworm.com/products/raspberry-pi-x735-safe-shutdown-auto-cooling-expansion-board ) onto the Prusa-Box from https://www.printer-box.com . Add…
Updated to have more room for power supply wires. Moved WAGOs around made channel for usb and RJ45 cable to exit. Opened up lid for more room for power supply wire exit.
Printed this Roomba filter adapter for Prusa Box HEPA filter from Chuck B: Prusa Box Roomba Hepa Filter w/ tabs and bottom edge by Chuck B | Download free STL model | Printables.com and noticed that at least with the latest Printer Box…
PWM controller mount for Prusabox enclosure filter mod. Mounts onto PSU electronics cover. Controller used: https://www.amazon.com/dp/B09P6D5TMV
I wanted to add a venting system for my PrusaBox to help vent toxic fumes. I took the 80mm model that PrusaBox provides and made it fit 100mm/4inch diameter ducting, like the one I bought: AC Infinity Flexible 4-Inch Aluminum Ducting I…
This model is used to set your Mk4 Prusa display on the PrusaBox, with only two printed parts. Hardware 15x M3x6 screws 15x M3 square nuts Print instructions Print settings: PETG Support : no Brim/raft : no Fill : 20% or more Assembly…
Needed to add a power cycle switch to PrinterBox's RBP cover for the Prusa-Box. The RBP with PrusaConnect/Link running does not have a way to power down yet. I used Colin Hill's idea when I used Octoprint. After a week, it seems to work…
Check out the latest variant right here → “ Prusa.Box ” Inspired by the awesome “Mailing Tube Cap” by Repkord, I want to design more boxes to use the empty cardboard parts from prusament spools. Hope you like it. I will do even more…
Gedruckt mit Prusa MK4 PETG / Düse 0.4 mm Schicht 0.2 mm (Quality) Niederspannung Dc Pwm Motor Drehzahlregler Modul 1.8V 3V-5V-6V 12V 2A 1803BK Material zur Montage der Modifikation 1 Zylinderkopfschraube mit Innensechskant M 3x8 8…
gedruckt Prusa MK4 PETG Düse 0.4 mm Schicht 0.2 mm Quality (weitere Einstellungen nach Bedarf) 1 Bodenplatte 1 Deckel 2 Haltewinkel 3 Lüfter 60x60x10 (TITAN 12 V TFD-6010L 12Z) 2 WAGO 221 Klemme (siehe Bild) 12 Zylinderkopfschrauben mit…
Beschreibung gedruckt Prusa MK4 IS PETG Düse 0.4 mm Schicht 0.2 mm STRUCTURAL (weitere Einstellungen nach Bedarf) 1 Bodenplatte 1 Deckel 1 Lüfter 45x45x10 (Sunon ME45101V1-000U-A99) 4 Zylinderkopfschrauben mit Innensechskant M3x8 4…
NEW ENCLOSURE FOR MMU3 CONTROL BOARD COMPATIBLE MMU2 FOR PRUSABOX, HIGHER TO CONTAIN THE NEW ADDED BOARD, REDUCER MOTOR CABLE MOVED UPWARDS I ENTIRELY REBUILT THE OLD CONTAINER TO CONTAIN THE ADDITIONAL BOARD AND PUT A PASSAGE FOR THE…
COVER FOR MMU3 CONTROL BOARD
This model is a variation of Collin Hill's lid design to hold a 4-way relay under the lid. Updated the model to the new version that goes with the Wago Connector. Included the STEP file for adjustments. I used the Elegoo 4-way relay. A…
1. Introduction Prusabox proposes a modular front to install a Waveshare 5" display on your enclosure. However, Waveshare screens tends to be quite expensive sometimes and difficult to find. Very similar touchscreens can be found on…
1. Introduction As an owner of an MK3 Prusabox, I think that the new design of the MK4 left/right doors is a very good design and upgrade compared to the previous system of locking. It gives a more robust way to close the door and also…
The Doors on my Prusabox MK4 won't align correctly because of too big Tolerances in the printed parts. The Front Doors were at slightly different height in the Middle and the side Doors were too low in the front area. I added longholes…
PiCam case, and two arms for top or bottom PiCam Boitier caméra PiCam avec 2 bras de fixation au rail nappe haut ou bas J'ai repris le fichier de PrusaBox du rail et de la fixation. J'ai dessiné deux bras et le boitier pour y mettre la…
I needed to upgrade from by C270 to the C920 webcam for my prusabox. There was one by @wilsondg_201245 but I couldn't get a good angle looking down. So I created a new design where I can have more tilt on the z axis. To keep the camera…
This set up is made to use MMU2 or MMU3 on top of an enclosure, using a filament enclosure. With autorewind system made with printed springs, you don't need any buffer ! Features: Compatible with Prusa MMU2 and MMU3 System Auto-rewind…
I redesigned this W1219 panel for the Prusabox. I absolutely hate sunken letters and filling them with color makes them look even worse. Even worse, the panel buttons were in the wrong place! I fixed the button alignment and also put in…
Holder for a humidity meter that mounts directly to the box. No need for the webcam rail. It bolts directly to one of the hinges. Simply replace the 6mm bolt with a 12mm bolt and it should fit nicely. Link to the meter I used
When i integrated my new MK4 Printer into the Prusa-Box by Printer-Box i realized, that my xLCD won't fit into the Front of the Modular Control Panel from Printer-Box. The Mounting Holes wouldn't align, the USB Connector had not enough…
A remix of the redesigned W1219 Modular panel for the Prusabox for light and fan control
i made this adapter to mount it on the rail for a raspberry camera https://www.printer-box.com/prusa-enclosure-webcam/
Love what Bera had designed, but I didn't love my position for the camera. I wanted as far back as possible to get as much of the build plate as possible, but the orientation of the first clip made that impossible. This remix takes Bera's…
Temperature Controller Bezel for Temperature Control Unit SHT20 From Ebay See video for more details https://youtu.be/zsTEjOPljjs This is a temp controller from Ebay (UK/US) designed to fit into Prusabox, but can fit into any other 3D…
Redesign of the modular front for the w1219 temperature controller housing, with switch for Raspberry Pi and longer internal groove for the w1219 circuit board. Orientate with the main face, face down on the bed. No supports needed. Print…
Redesigned base plate panel to fit 30mm fan for Prusa Box modular front. Print Settings Printer Brand: Prusa Printer: I3 MK3S Rafts: No Supports: No Resolution: 200 Infill: 25 Filament: any PETG Category: 3D Printer Accessories
Modification du guide PTFE pour le filament dans le caisson PRUSA BOX
Love how little space @Anthem's PrusaBox-AirExhaust-external takes but wanted something that would “encourage” the hot air to go up, not straight out the back or possibly down toward the floor. I decided to use the model from…
Habe Bauteil [Printer-Box] Prusabox 19_mk4_motherboard_cooling_tube_bottom_v1 neu in 2 Versionen aufgebaut. kompatibel mit Anbaulüfter ohne interne Lüfterhalterung gedruckt (ohne Stützmaterial) mit Prusa MK4 Filament Prusament PETG Düse…
