Small support to put a logitech webcam on the side of the Z axis. You'll need 1 M4x10mm and a nut to mount it. Print Settings Printer Brand: Velleman Printer: K8200 Rafts: Doesn't Matter Supports: Yes Resolution: 0.2mm Infill: 10%…
This is a case with an 80mm fan mount for the Bigtreetech SKR V1.3. You willl need to get two M5x12mm screws to attach it to the K8200, four M3x10mm with matching nuts for the mainboard and four M4x8mm to screw the fan to the cover. You…
Designed to be used with the original Hotend mount and with a maximum 22mm Hotend Parts needed -4 M3 Screws -1 25mm fan Simply disassemble your Hotend support, then put your new fan mount and put again your Hotend and your Hotend mount.…
A simple and efficient mounting bracket for a Traco TPP-150 series Power Supply Print Settings Printer: K8200 Rafts: No Supports: No Resolution: 0.2mm Infill: 10 Instructions You'll need to print two times the bracket, two M5 by 8mm Bolts…
This is just a remix from Danyboy's design, but the cable is on the opposite side. Print one "Alim_droite" and one "Alim_gauche" parts. Print Settings Printer: K8200 Rafts: No Supports: No Resolution: 0.2mm Infill: 10 Category: 3D Printer…
Il suffit simplement de dévisser les deux espaceurs qui maintiennent la Hotend d'origine en place, de venir glisser la nouvelle Hotend dans la pièce, de mettre la pièce et la hotend dans leur emplacement, puis de venir visser les deux…
Hello dear maker! after a long search on thingiverse i've found this nice fan: http://www.thingiverse.com/thing:814286 . The problem i encountered was, that there wasn't any holder(for a K8200 / 3drag) for this fan at all! So i've decided…
I modified http://www.thingiverse.com/thing:395908 added lightening holes and slot for mounting with clamp Instructions Frame is for mounting left and right, fix with clamps 180x4.5 mm. To mount without any problems at the bar, slightly…
Clip fermacavi per stampante 3d K8200 / 3DRag da: 5 mm 10 mm 15 mm Category: 3D Printer Accessories
The is a mount for a genuine E3D v6 all metal hotend and E3D Titan extruder for the Velleman K8200 / 3DRAG 3D printer. Only one part is required to mount the hotend and extruder, but I also made a modified mount for the fan duct produced…
Mounts the Bulldog XL Extruder rock solidly to the Z-bar of the K8200. Inspired by this . I wanted a simple solution that's ridiculously rigid, and at the same time doesn't force you to disassemble the printer; and this is it.…
What is this? A rig to mount a small 9G RC servo, with an arm mounted Z-endstop, next to the extruder on a K8200/3Drag to enable the Auto bed leveling feature in recent Marlin . I had to modify the probe holder by zenmaster a bit to…
This simple construction are for upgrading your K8200/3Drag to GT2 belt on Y axis. It is a direct replacement, reusing the original mount screw and holes, adding the missing belt tension. For complete upgrade of Y axis to GT2, you need:…
Based on http://www.thingiverse.com/thing:369891 , this mount has a 90 degree angle, so that it fits on the right upright on the K8200. Category: 3D Printer Parts
This is a further refinement of my cable driven Z axis for the K8200 or 3Drag. It uses a cable loop to ensure the Z axis is driven from both ends, and at the same time provides a large degree of "z wobble" isolation, though a severely…
This is not a mod for the faint of heart, it requires an almost complete disassembly of the printer base frame. And probably a lot of swearing and frustration, but I am quite pleased of how it turned out. I am marking it as a work in…
Completely redesigned in OpenSCAD to lower the base of the hotend and make it easier to fit a slot mount hotend in place of the original Updated to easily switch between 3 and 1.75mm paths, and to replace steep overhangs with small…
Here's my rebuild of the X and Y axis of the Velleman K8200. It features GT2 belts, tangential clamping for the use of Igus linear bearings (Also works for normal ball bearings). It is way more sturdy than the original design and it…
Edit 12/06/19: Added Pictures of the finished solution. I have been looking for a great way to make the Z axel go up and down. I have tried a DOZEN designs and none where what I was looking for. Now I have designed my own one and it is in…
If you have mounted the E3D V6 on the extruder, the original adpater is too high, this one is 2 mm lower and will allow it to be mounted. It might need a Little CA glue ;-) Category: 3D Printer Extruders
Yet Another X-axis holer for the Velleman K8200/3Drag printer. I have been looking for a stable holder with the end stop mounted on it, as i dont Think that there is a Point in moving the screw. This is designed so that you can cut of the…
Made my own mounting plate for my QR extruder. Combine with the top part from the standart mount from Bondtech homepage: https://www.bondtech.se/sv/kundtjanst/utskrivbara-stl-filer/ Works great. Category: 3D Printer Parts
Tensor para correa del eje X de la impresora Velleman K8200 ·Configuración de impresión FDM Impreso con calidad 0.2 de resolución y relleno (0.4) cada 2 capas para ahorrar tiempo de impresión. La tasa de llenado debe ser al menos del…
K8200 aluminum profile to mount of the HeroMe Gen7. The mount should allow all the interchangeable hotends and cooling solutions for the HeroMe solution. Do as you will with it. This assists in reviving an old dinosaur bedslinger with…
If you are using the 16T GT2 pulleys on a K8200/3Drag The belts will collide, and the Y belt will rub on the smooth rods of the X axis. To provent this, you can use this mod that raises the Y axis by 12mm. This way the Y belt will be…
This is a mount for a 18mm inductive probe. It will mount the probe behind the extruder using 1x M5 screw and nut, so you will have enough clearance to add whatever you want. Print Settings Printer: K8200 Rafts: No Supports: Yes…
You'll need: 4x 608 Ball bearings 2x M5x12 screws with corresponding nuts 4x M6x30 screws with corresponding nuts Print: 2x Spool Holder Arm 4x Spool Holder Spacer 4x Spool Holder Roller
Didn't have the right bearing but did have pom wheels for the Ender 3 Pro so I made new 'wheel covers' to fit those (24mm internal diameter). Also didn't use the supplied spacers and just used washers.
Original made by Rob Mitshi was for E3Dv5 Category: 3D Printer Accessories
Precise calibration of the zero point Instructions Layer 0,2mm infill 15% perimeter x3 Link to micrometer: http://www.ebay.com/itm/331109043919?_trksid=p2059210.m2749.l2649&ssPageName=STRK%3AMEBIDX%3AIT Category: 3D Printing
This is my 2nd upgrade of the K8200 3D Printer. It will transform this printer as a Prusa Mini. Part 000424 : Sun gear, 20 teeth, 0,85 modulus
This is my 2nd upgrade of the K8200 3D Printer. It will transform this printer as a Prusa Mini. Part 000425 : Planetary gear, 23 teeth, 0,85 modulus
This is my 2nd upgrade of the K8200 3D Printer. It will transform this printer as a Prusa Mini. Part 000426 : Planetary holder
This is my 2nd upgrade of the K8200 3D Printer. It will transform this printer as a Prusa Mini. Part 000427 : Planetary flange
This is my 2nd upgrade of the K8200 3D Printer. It will transform this printer as a Prusa Mini. Part 000430 : Planetary shaft (use 2)
This is my 2nd upgrade of the K8200 3D Printer. It will transform this printer as a Prusa Mini. Part 000432 : E motor mount Replaced by : https://www.printables.com/fr/model/599730-k8200-upgrade-2-e-motor-mount-v2
This is my 2nd upgrade of the K8200 3D Printer. It will transform this printer as a Prusa Mini. 66 teeth ring for epicyclic gear train. Part of the extruder reducer.
This is my 2nd upgrade of the K8200 3D Printer. It will transform this printer as a Prusa Mini. E motor mount v2
These thingies I made in order not let the printbad make contact to my enclosure. Instructions I used three each to get enough space. Category: 3D Printer Parts
My attempt for an eclosure Instructions Part list 2 square meter polystyrene ? 3 mm bolts 12 mm long ? 3 mm bolts 16 mm long ? 3 mm spacers ? 3 mm nuts ? Chassis fasteners 2 bottom corners 2 bottom corners 2 front connectors 3 front…
A common Housing for a Velleman K8200/3Drag Controller and a Raspberry Pi with Camera (especially for octoprint) Take the webcam housing and the cover from here: Raspberry Pi Camera Housing Attach controller and Pi with short 3 mm pan…
Spacer + T-slot block to mount things with 3 mm distance to the alfer coaxis 27,5 aluminium extrusions. Use M3 screws and nuts for the recommended M3 Version or 3,5 to 4 mm spax screws for the not recommended standard version. 2018-01-16:…
An K8200 / 3Drag enclosure for the RepRap Full Graphic Smart Controller . It was my design goal to achieve a solution with as few components as possible and preferably without screws. In the design process, my goals were achieved, but the…
ClipOn Fan mount for standard 5015s (50x15mm) centrifugal fan used in many 3D printers today (as Prusa i3 MK2). Mount is the blue part on the picture. The cooler fan that comes with the K8200 kit is far from optimal - with unfocused part…
Upgrade parts for the K8200/3Drag extruder to enable use of 3mm flexible filament such as NinjaFlex and TPE (shown in blue). Teflon tube in each part ensures a non stick filament feed. >> If you like it, please leave a like, rating or a…
The original kit has too much wobble on the Z axis, resulting in shifting and uneven layers. This design is for a minimal but rigid Z axis, using a trapezoid lead screw. There are only changes to the original design, where needed. The new…
40mm fan mount for the All-Metal E3D v6 Hot-End to Velleman K8200/3Drag standard filament extruder. Fan duct snap on reusing original extruder screws and spacers, optimized for robustness and easy print. The 40mm fan is more quit than the…
This simple construction are for upgrading your K8200/3Drag to GT2 belt on X axis. It is a direct replacement, reusing the original mount screw and holes, adding the missing belt tension. For complete upgrade of X axis to GT2, you need:…
This simple construction are for upgrading your K8200/3Drag to GT2 belt on Y axis. It is a direct replacement, reusing the original mount screw and holes, adding the missing belt tension. For complete upgrade of Y axis to GT2, you need:…
Correct bed leveling is essential for good prints - Marlin firmware now has this awesome feature of measuring the bed and automatically adjusting the Z axis when printing. As this YouTube video demonstrates. I had a small used 8mm…
K8200 and 3Drag filament guide with one bearing. The parts can be printed, except for the bearing and the countersink wood/plastic screw 3x25mm. Update: Version for both bearing 6000ZZ and 608ZZ (skateboard bearing). The larger bearing is…
This is a K8200/3Drag frame mounting clip with locking screws. It is based on my redesigned of the K8200 Frame Wire Clip On . Next step will be to use the clip in other designs there could benefit from the more secure frame clip. This…
Simple K8200 and 3Drag frame snap on clips to hold the wiring as a replacement for the nylon strips. Based on BVD2e's model http://www.thingiverse.com/thing:444323 with few modifications. Update: Added variant with three profiles and STEP…
The end stops for X and Y axis are difficult to adjust as they tend to get loose when unscrewed. The original two screw construction is complicated and I made this simpler "one screw" replacement for the axis. There is no need for precise…
30mm fan mount for the All-Metal E3D v6 Hot-End to Velleman K8200/3Drag standard filament extruder. I liked the original fan duct and mount from E3D-Online and wanted the Hot End to mount on the original K8200/3Drag extruder using the…
This is a base setup to create modifications on this printer. I converted many parts from the OBJ model of http://www.thingiverse.com/thing:203292 but, many of them have been measured by hand. It have been made on Catia V5, aprx 20 hours…
