Remixed Simon's Orbitool mount for an actively heated chamber, which requires a fan on the toolboard. Added 4010 fan mount. Requires additional M3 insert and fasteners. Print with 0.4mm nozzle and paint on support for all of the thin…
I designed this 4-bar-linkage Hinge, to have the Doors of my Vcore4 400 fold outward to the side of the printer in a controlled way. I’m using 6mm PC Panels for the door, and 6mm ACM + 8mm Insulation for the Sidepanels. I also added a DXF…
Update 3/3/26: These retractors last around a 1000hrs of print time before the winding mechanism fails. The stock piano wire broke at the extruder, so I needed something to hold the umbilical up and out of the belts / print. Simple…
I designed this 4-bar-linkage Hinge, to have the Doors of my Vcore4 400 fold outward to the side of the printer in a controlled way. I’m using 6mm PC Panels for the door, and 6mm ACM + 8mm Insulation for the Sidepanels. I also added a DXF…
Vcore4 Electronics Enclosure Seal with guiding lip for easy alignment This can be printed in PLA, PETG, TPU etc. My preference was TPU cause it absorbs more the vibrations.
Mounts for temperature sensors: 3mm thermistor for the 2020 extrusion (updated model with less blocking of the extrusion surface) 1.2mm thermocouple for the 2020 extrusion 1.9mm or 3mm thermistor for the Rapido hotend: The mounts for the…
Schleif-tec X-Gantry for RatRig V-Core 4 Spacer https://spannsysteme.shop/produkte/x-gantry-for-ratrig-v-core-4
I create a pcb for the lightning of the corner at the RR VC4. So i added 2 more holes in the backside for a cleaner wirering and my custom PCB, also i flat the diffusior a bit to improve the light what is coming out :) if you are…
I want to use an either-net cable on my Raspberry Pi instead of WiFi. There is not a provision to get the cable through the bottom panel. I also made a second port for the Z motor wiring to enter from the bottom. The holes are big enough…
I don't know what I was doing wrong (probably just the wrong size and too thick of zip ties) but the old zip tie to guide the belt around the corner wasn't working for me. I got fed up and designed this guide. It doesn't make it easy, but…
This replaces the bottom two corners and bottom plate of the steel electronics enclosure with a 75 mm deep expansion to house the on/off switch. There is also space for adding something else in the future, or just more space for wire…
This mounts to the side of the 400 mm enclosure with M6x16 socket head screws, through the existing holes. Use 4 M3x8 screws and M3 heat sinks for the side of the panel. I didn't like the buttons on the earlier models, so this uses…
These hinges are designed to align with the holes of the standard RatRig VCore 4 front panel, enabling it to be converted into two doors. While originally intended for 4mm side panels, these hinges are also compatible with thinner or…
After getting frustrated by belts slipping out of the front toolhead belt clips and then the headset insert torquing out trying to get better grip on the belt I decided to try something different. In the style of VZBot belt clips but…
After my success with brad nail belt clips on the toolhead I remixed the y-belt-clamp block similarly. The belt passes through the center of the single piece print (no heat-sets, and just two of the 5 bolts) with teeth locked then after…
To create room for bracing the frame I combined two components, the z end stop and z lead screw constraint parts. The remix now only uses 2 bolts total instead of three. This is now compact enough to bolt on an 8 inch shelf bracket across…
Insulation supports for the back wall of a Vcore4. 220 length for the upper wall, fits all sizes. VC4-300: 255 for the lower wall. Also included is a version of the 255 suport with holdet for a 3mm PT1000 temp sensor. VC4-400: use file…
Update 3/3/26: These retractors last around a 1000hrs of print time before the winding mechanism fails. The stock piano wire broke at the extruder, so I needed something to hold the umbilical up and out of the belts / print. Simple…
added a different belt path and added teeth to better grab the belts walls: 4-5 Infill: 25% Top/Bottom Layers: 4-5
Mounting brackets to mount the 1 meter long version of the Blazecut tube. Tries to lift the tube near the ceiling and close by the extrusions, so that it would minimally interfere with the umbilical. Also, the brackets should keep the…
Don't want to buy a 100-pack of hex spacers in order to use only 1 for your Vcore? No worries this hex spacer can be printed and used. Requirements: -filament that can withstand some temperature (F.E. abs or asa) -2 M3 heated insterts…
I try to reduce the sharp turns in the (reverse) bowden to minimize drag. To that end, I use these guides to allow for a smooth path while using the BTT SFS2, mounted with the nice…
I wanted a filament cutter requiring minimal disassembly of the original toolhead. Inspired by other designs, I created this one—and it works surprisingly well. Print settings The main part was printed in ASA with a 0.2 mm layer height ,…
RatRig VCore4 Titanium Tube Funssor CNC XY 6x M5 x 10-12mm 6x M5 Screw nut
Routing the PTFE tube from the back corner to the print head was problematic because it would droop onto the build plate. I Remixed the RatRig Gantry Mount top and bottom to support the PTFE Tube. The top support uses a standard push-in…
Front Corner brace that works with the standard RatRig VCore4 Front Panel mounts
This is a mash up of the 608 bearing based spool roller that there are already many variations of. It is set up to feed out the back, so the rollers are recessed in the middle. It is still a work in progress because I have not finished…
Camera Mount for RatRig using a SVPRO 5MP 30FPS USB Camera with a 120 degree field of view. Camera: https://www.amazon.com/dp/B0D8SS2KNZ Clone the CameraMount stl and mirror it for the second bracket. You will need 2x 3mm screws and brass…
I modeled this opening insert to guide cables to the electronics, which are outside of the enclousure (E-Stop and Klipperscreen). The insert press fits into the metal sheet. First you need to cut out the spokes, where the insert will be.…
Slightly extended oozeguard for the Ratrig Vcore4 to allow for the extended length of the Chube Air nozzle. You will need to remove the wipers for these to fit when the bed is all of the way up and the printer is all of the way at Y=0 You…
This gommet fully protects the cables in 360° and has a closed design compared to the original model from ABS. See picture two for comparison. V3 is larger at the top to hold the gommet better in place. Printed in 95A TPU.
The parts are designed for printing from PA6-GF30 Materials used: 1. Wire harness support - 4 x 1.2mm stainless steel spring rod 2. Fabric cable ties, 12mm wide 3. 22mm CPAP hose CAUTION - the harness supports are sometimes attached to…
The E-Stop holder is made to mount it to an RR vcore4-400mm with enclousure on the top right corner. I will upload pictures once I've mounted it. The E-Stop itself is mounted with an M3x10 screw in the heatset insert. Only one mounting…
Top inlet duct for the front 4010 fan on a Vcore4. This drops the heat break temperatures by 5C, by eliminating the hot air pulled off the print bed. Helps in an enclosure where the air is stagnant and prints are often placed in the…
I don't have a convenient place to keep the front and top panels, so these brackets hold the panels on the side of the printer. I don't try to print with high accelerations, which would be a problem because the panels wiggle. Someone else…
Simple two place front panel support bracket for the Vcore4. Allows you to place the bottom of the panel spaced away from the seal to allow venting of the enclosure while still getting most of the sound deadening effect and engagement of…
This is a simple camera mount for a Ugreen 1080p camera for my RatRig vcore4. You need two M6x12 screws and one M6 T-Nut which should be left over after the build. It can be used for any 3030 profile. I included the CAD file, so you can…
Larger versions of the Ratrig vcore4 "Electronics Wire Clip" to accommodate more cables
Vcore 4 is using long screws as the shafts for the belt bearings near the motors. During installation and maintenance these screws are held in place by friction on the screw head, i.e. the counterbore is tight. This is somewhat sensitive…
Something to hold panels up to 6 mm thick for easier mount & unmount by one person.
