This places the center of the chuck in the anchor 2 (0, 0) position. Print the subplate on an angle (30 degrees is ideal) to given it higher shearing strength, and be careful when installing the chuck to not over do tightening it. The…
The design makes use of the 4 x 9mm pins for alignment. The pin holes are modeled with a very tight fit (0.05mm clearance), adjust as necessary. The center hole needs to be precision threaded M14x1.00. Any deviation off centre will render…
Adapt a Cen-Tec Quick-Click vacuum hose to the 22mm vacuum port on the Carvera Air. There's a space for two 15x2.5 mm magnets secured with an m3 countersink screw. The magnets add a little extra security to the press fit of the adapter.…
It can be useful to minimize collisions on the 4th axis to remove the laser from the spindle head, and instead only attach it when required. This adapter plate is secured using the screws on the top of the original Carvera laser to allow…
Joe N style alignment, where instead of pins it uses the anchor, makes it much easier to cutout. Just make sure to apply pressure towards the anchor2 corner while screwing it down. The bolt needs a M14x1.00 thread to secure the chuck from…
The air assist is great for clearing chips and cooling the tool and workpiece. But, having the nozzle out to the side means it is ineffective in deeper pockets and when the workpiece blocks the nozzle. This design slips over the existing…
Adapter to use the tablet holder for supporting a WiXC WBH04 Pendant in the original Carvera tablet holder. There is a small slot at the top to insert the metal bracket that comes with the pendant, so that it's magnetically held in place.…
This is designed for the new harmonic drive 4th axis. Be aware that this increase in height is at the reduction of the spindle clearance. The 9mm blocks are the largest you can use on the Carvera Air and see be able to probe the 4th axis…
This replaces the vacuum hose mount and allows you to attach a 8mm rod for more flexible accessory mounting. Required hardware: M3 Ultrasert II Heat Inserts - https://www.mcmaster.com/94180A331/ M3 Set Screw -…
A simple cover that can be placed over the exposed end of the Z-axis ballscrew on the Carvera Air to prevent chip ingres
I printed mine in PETG but most any filament will do. Two short M5 bolts attach using existing holes. I used M5x5
Still a WIP as I test it out and find new pain points. For instance I need better door sealing and covers for the linear rods still. This is a continuation of some of my earlier work with some expansion by P.Tech…
Carvera bit holder with two-color stay-in-place dividers and stand adjusted for a looser fit.
Unfortunately it's hard to source stock that is the size of the carvera airs bed sometimes. So I created this extension that keeps the cover slightly opened, just enough to allow some extra room and keep the lid down. In the photos I'm…
Replace the tablet holder with a camera mount. Remix was to add a 1/4-20 boss as is standard for camera equipment.
This mount can work with either of the following two cameras: Arducam IMX291 Board (recommended. use the -arducam parts) ELP AR0330 Board Instructions: Print: For the ELP camera: camera-top.stl camera-back.stl For the Arducam camera:…
When looking at the machine, make sure the fan blades are slanting from top left to bottom right as shown in the picture. There is now a shouldered version stl if you are having issues with the fan sliding up the spindle
Attach to side mount point with the M4 screws. I printed a couple regular short arms (the small arm variant!), and a couple mirrored arms so I had more options to mount the arms in a configuration that I liked. The UV lamp mount I used M5…
arrange the bits , left row used to set the loaded bits inside the machine
A template for pre-drilling of spoilboard for MATERA CARVERA desktop CNC
I created these small interlocking bit holders to help organize the many bits for our Carvera desktop CNC machine. They angle the bits back a bit for easier viewing and snap together nicely with one another to allow for whichever…
Modified Fae's risers to allow for M6 ULP screws with the SMW fixture plate.
This places the center of the chuck in the anchor 2 (0, 0) position. Print the subplate on an angle (30 degrees is ideal) to given it higher shearing strength, and be careful when installing the chuck to not over do tightening it. The…
An CARVERA (by MAKERA) accessories holder V2 - added 3mm collet and
Upper part may be printed using PLA or PETH, requires support inside Lower part to be printed using TPE32
This is a mounting plate for the back of the Carvera Air. It converts it to a 32mm out. There is also a few adapter for my Vacuum. https://buymeacoffee.com/ElectricFjord I show it in my video:
This is a tool holder for your 3.175mm (1/8") bits so that you can stage your tools! If you want colored text change the color on the last few layers!
These models are various Brackets for the Carvera and the Carvera Air. There are normal ones that are similar to the one that comes with the CNC. There are ones that are close to the normal ones, but the holes are chamfered instead of…
Model of the spoilboard for the carvera air in various file formats
I made this simple cylinder guide to use in the Makera bit collar installer. Mine did not come with spacers/sleeves for a 3.175mm (1/8") milling bit, so when I would put one of the collars on with the tool it would sometimes be a bit…
Made this sleek, stiffened design to connect my DeWalt Stealthsonic Vacuum. Used 4 M3 x 8 screws to attach utilising already existing threads.
The design makes use of the 4 x 9mm pins for alignment. The pin holes are modeled with a very tight fit (0.05mm clearance), adjust as necessary. The center hole needs to be precision threaded M14x1.00. Any deviation off centre will render…
Carvera Vacuum Adapter with a TPU part for sealing. I used elgoo PETG orange because I have a lot of it. will also work with PLA. I used 95A TPU other hardness ratings will likely work as well. Use tree supports on both parts, print wider…
This is 1/8" Bit holder with Collar made for my Carvera Air. Collar 7.6mm. Large and small version. Both have Numbers going out or inwards. Whatever is preferred. For a single color printer the easiest is just to get the slicer to request…
Designed it to organize all the bits for my Carvera Air. For all the bits that didn't have a case, I also designed this bit box to give them one: https://www.printables.com/model/1189757-18-bit-storage-case The storage units attach to one…
Vacuum hose adapter for the Original Carvera (Not AIR) and the Fox Alien HFS-800 dust exctractor. Should fit any 38mm OD vacuum hose. Fit snugly for me on both sides but you may need to fiddle a bit with scale to get the proper fit out of…
This is a vacuum adapter which converts the 45mm / 1 7/8" Stealthsonic 6 gallon model hose to the 22mm port on the back of the original Carvera C1 desktop CNC. It also has a flat mounting surface for VHB tape or area for screwing in from…
I was surprised by how loud my 6 gallon StealthSonic vacuum was when I hooked it up to my Carvera CNC machine. It turned out that the immense increase in airflow through the Carvera's small corrugated tubing was generating more noise than…
This is a modification of the lower parts and vacuum manifolds for the Carvera Back Panel Isolation Mod by Fae Corrigan. You will still need the upper parts from Fae's mod located at…
Ues this with the FoxAlien low profile vise to get things squared up. Vise: https://www.amazon.com/Profile-Workholding-Machine-Milling-Worktable/dp/B08C26KVD3
Adapt a Cen-Tec Quick-Click vacuum hose to the 22mm vacuum port on the Carvera Air. There's a space for two 15x2.5 mm magnets secured with an m3 countersink screw. The magnets add a little extra security to the press fit of the adapter.…
This is a multipart model that adapts the vacuum port on the Carvera Air. I advise printing the elbow on the flat face with organic tree supports. The parts glue together with superglue (split up like this for ideal printing) The magnet…
Carvera Air lazer module gridfinity storage. You have place for the cable also.
Gridfinity 2x1 storage for your Makera collar tool.
It can be useful to minimize collisions on the 4th axis to remove the laser from the spindle head, and instead only attach it when required. This adapter plate is secured using the screws on the top of the original Carvera laser to allow…
These are .step files for various bit collars for the Carvera Air (and original Carvera) CNC machine. Included files: 3.175mm (1/8") 4mm 6mm 6.35mm (¼") You may have to adjust for hole compensation on your own printer to make sure it fits…
Joe N style alignment, where instead of pins it uses the anchor, makes it much easier to cutout. Just make sure to apply pressure towards the anchor2 corner while screwing it down. The bolt needs a M14x1.00 thread to secure the chuck from…
There are the DXF files for the Carvera Air size spoilboard, in metric and inches. There are also the fusion files since many people ask for them. I also added premade g-code files for the carvera air with 2 and 6 % power. I recommend 6.…
Holds 110 Carvera bits, 5 collets and the collet change tool. Note: There are two different files. The larger one fits on a CORE One print bed, and the smaller one should fit fine on a Prusa MK3 sized bed. The only differences are that…
This model contains 12 columns and 8 rows of bit holder pockets, as well as two larger pockets for bits included with the PCB kit. In the front it has numbered round pockets to prepare all the bits for a job. Also in the front is a…
This adapter plate covers up the previous mounting standoffs in the PSU area, and allows you to install a Meanwell EPP-500-48 PSU in place of the 200w spindle PSU on the Carvera. This is required for running higher power Spindle motors,…
Presentation Easy to print and setup side mounted bit holder. Store up to 6 bit with it's casing. You can also store your hex screw driver, clamps, screws and pins. Setup Print Right or Left variant depending on which side you want your…
I printed this upside down using a 10% gyroid infill and tree supports only on the build plate and only with critical regions supported. I set the bridging to 10mm so it wouldn't put supports into the bit squares and they still printed…
With this pipe you can extend the internal dust pipe to clean up after a job. You can reach almost all build space. The freecad cad file is included for your own mods. Printed upright, so you would need a printer with 260 mm build height.…
For those wiring in a 3D probe to the existing wired probe port on the Carvera Air, this will tidy things up a bit.
Replacement Backplate for the Carvera Air to connect a 100 mm Air Duct for Smoke remval during use of the Laser Module. Includes optional Places to Pressfit 6mm magnets (up to 10) intended to hold the Original Backplate on the Inside of…
Revised Carvera Spindle Fan by Fae Corrigan. This version has slightly thicker blades plus other improvements.
Tool holder to carry the following items: 2X Side Mount Clamps 4X Top Mount Clamps 9X Alignment Dowels 6X Bit adapters / Probe tail shaft adapters 16X Bolts (Up to M6 possible) 12X Bits with standard case 2X Spindle Collets (for various…
Fits 110 Carvera bits, 5 sizes of collets, the collet change tool and a tray for various things. This is a redesign of fungus_wine 's Bit Organizer, slightly compacted to fit beds of smaller printers like the Ender 3 series and similar.…
M6 bolt to hold the arm onto the lube cube M6 bolt & wing nut to hold the arm onto the bracket Long m4 bolts to mount the bracket to the CA1, replacing the existing M4 bolts at the top of the fan (after drilling holes in the plastic…
Print in a contrasting color to your M6 plugs for easy identification.
Print in a contrasting color to your M5 plugs for easy identification.
The air assist is great for clearing chips and cooling the tool and workpiece. But, having the nozzle out to the side means it is ineffective in deeper pockets and when the workpiece blocks the nozzle. This design slips over the existing…
This is de straigh version of the Carvera clamp. I machined it out of the 5mm thick aluminium that came with the Carvera. You can also 3D print it ofcourse to have a softer clamp that wont hurt your machine when you make a mistake and let…
Makera provided a nice little box where all this stuff fits in, but the issue was I was constantly looking for some room to place it and open it, and I kept dragging that thing between storage and usage places, so why not put it on the…
⚠Disclaimer⚠ Use this model on your own risk. I will not be responsible if you damage your CNC or Mobile device using this model. Putting a $1000+ Iphone near a bit rotating at 10000 revolution per second is maybe not the best idea ! I'm…
⚠Disclaimer⚠ Use this model on your own risk. I will not be responsible if you damage your CNC or device using this model. Putting a $300+ camera near a bit rotating at 10000 RPM is maybe not the best idea ! I'm dumb, this does not mean…
This is a direct replacement for the foam insert you received with your Carvera CNC toolkit. Using this insert, you can place gridfinity organizers however you like. The main insert, that you can't change, holds the screwdriver, pins,…
For the heat shrink challenged.
This adapter connects the 22 mm dust port of the Makera Carvera CNC to the 36 mm Cleantec hose system of Festool vacuum cleaners. It allows you to use a Festool dust extractor as an external vacuum instead of the internal dust collection…
This is a blank acrylic sign for the Carvera-air Led sign project. I made this because I did not want to waste the supplied materials on a random led sign with a smiley face etc. upload the file and include your engraving files on-top.…
This is a mount for attaching an endoscope camera to the Carvera to allow for visual alignment of double sided PCBs. Basically you need to drill at least 3 holes on the top side of your PCB all the way through, measure the centered…
Adapter to use the tablet holder for supporting a WiXC WBH04 Pendant in the original Carvera tablet holder. There is a small slot at the top to insert the metal bracket that comes with the pendant, so that it's magnetically held in place.…
Carvera Air Laser Exhaust Mod This is a replacement back plate for the Carvera Air, designed to mount an 80×80 mm exhaust fan (available from AliExpress) with a duct for external ventilation. It helps reduce the smell produced when using…
Use this tool to hold a Dial Indicator with a 3.178mm endmill in the Carvera spindle. This works with both the Original Carvera (C1) and Carvera Air. A shorter version of the tool (65mm) works on the Z1 Using this tool you can rotate the…
Print with the large bore facing down and no support. There are 2 sacrificial bridge layers that you will cut through after printing to open the existing slot. Then install a heat set M3 insert and screw.
Do you also find it so anoying that when you are done with your lathe you find stock for days underneath your bed? That's because the chips and dust go into the hole, you miss some when vacuuming and your holes can get clogged or the dust…
This is designed for the new harmonic drive 4th axis. Be aware that this increase in height is at the reduction of the spindle clearance. The 9mm blocks are the largest you can use on the Carvera Air and see be able to probe the 4th axis…
Plugs for the bed mounting bolt counterbores.
Found out after printing faecorrigan's original bit collar install tool that the cool included with my Carvera has a 30mm end, not 20mm. Fortunately they uploaded a Fusion model so I modified the tool to work with my larger tool, and…
I bought a cheap $5 dial indicator from AliExpress to use for measuring how level my Carvera Air bed is. The hole spacing on the indicator is 32mm and the backplate is 51.5mm. If this matches yours, you should be able to use this. Prints…
A 3d probe storage holder that fits in the current wired probe storage place so you don't need to remove the current plastic part that is really hard to remove without stripping the heads of the bolts. I don't need the current 3d probe so…
Printed with PETG, 4 Perimeters. Use CA or similar glue for 8x2mm magnets. FreeCAD file attached. Picture shows old version. New one has extended tube on the Makera side and 6 Magnet recesses instead of 4.
This replaces the vacuum hose mount and allows you to attach a 8mm rod for more flexible accessory mounting. Required hardware: M3 Ultrasert II Heat Inserts - https://www.mcmaster.com/94180A331/ M3 Set Screw -…
When using some third party fixture plates such as the one from SMW with the Carvera Air it is recommended to cover the tool length sensor circuit board to prevent short circuits caused by metal chips. This can be achieved using hot glue…
Do you also find it so anoying that when you are done with your anchor 2 vice you find stock for days underneath your bed? That's because the chips and dust go into the hole, you miss some when vacuuming and your holes can get clogged or…
With this adapter you can connect your Metabo ASA 30 H PC vacuum to the Makera Cavera Air CNC.
A 3D-printable tool insert for the Makera Carvera Air CNC that fits the universal phone/tablet mount that is included with the CNC. The tool insert fits one to seven tools including their storage case for easy organization and overview.…
A minimalistic 9x3 Gridfinity ( https://gridfinity.xyz/ ) fixture that holds the Carvera Air 4th axis module. The fixture consists of 4 corner pieces that each have a cutout for you to easily label. The corner pieces are in total 12mm…
A minimalistic 6x5 Gridfinity ( https://gridfinity.xyz/ ) fixture that holds the Carvera Air toolkit foam insert. The fixture consists of 4 corner pieces that each have a cutout for you to easily label. The corner pieces are in total 12mm…
As I have replaced the original xy probe on my carvera Air with a 3D probe and still liked to use the Margin function, I added two line lasers to the spindle cover. Where they cross is where the Bit will cut. I wired them in parallel to…
A simple cover that can be placed over the exposed end of the Z-axis ballscrew on the Carvera Air to prevent chip ingres
I printed mine in PETG but most any filament will do. Two short M5 bolts attach using existing holes. I used M5x5
Still a WIP as I test it out and find new pain points. For instance I need better door sealing and covers for the linear rods still. This is a continuation of some of my earlier work with some expansion by P.Tech…
