This a 4 x 3 gridfinity base/gauge holder that holds standard 6 unit tall bins and a screw gauge that is 5 mm thick. I use it with this imperial screw gauge and these gridfinity labeled lightweight bins . Allows one to use the gauge with…
The original was a bit tight so i just moved the faces to make it fit better. made it so you can mount the thermostat in any corner.
Float level gauge for Rotax 912/914 carburetors. P/N: 877 730. Made from ASA.
Hey guys, complimentary to the shim posted by “NeedItMakeIt” here, I designed those shims to level the bed in it's back corners (those corners are hard to level using only the 3 leadscrews as adjustment). They are designed to be placed…
A Slope Angle Factor Gauge that attaches to a rifle and displays the Slope Angle Factor based on the elevation/depression angle of the firearm. It requires one (1) M4 nut, one (1) M4 washer, four (4) M6 nuts, four (4) M2x6 flat or pan…
I'm currently building a small 3d printed robot. I needed to measure some hardware components to be incorporated in the build and I decided to make my own tools. This box contains a set of radius gauges both for convex and concave parts,…
Stores VC Design's radius gauges in a Gridfinity block. When closed, the bin extends past its footprint.
This gauge holder fits perfectly in the place of the drivers air vent on a Volvo 940, not compatible with older 740 dash!! For 52mm or 2 1/16" gauges. The pre-designed supports can be cut off easily, so you won't have to enable supports…
Simple marking gauge. Use a pin or nail for the marking pin. Nice in-use - the body locks up easy with turn of screw.
This box was made for calibers, as well as for dies and similar items Don't forget to scale the model to your needs in the slicer, and don't forget about tolerances :)
I couldn’t find a choke tube holder that seemed practical for field use, so I designed this. These holders are made to fit 12-gauge shotgun choke tubes. The dual version has holes for attaching it to a lanyard or similar, and both…
Changing blades on a bandsaw or large sawmill requires properly setting the tension of the new blade. If you run a sawmill these gauges ( tensiometer being the $20 word for it) are part of the required tools of the trade. Unfortunately…
A handy device for checking letters before you send them. Anything that doesn't fit through the slot doesn't qualify as a letter and will need extra postage, going either as a large envelope ("flat") or as a parcel. See the Domestic Mail…
a quick set of feeler gauges. I made them for checking gaps on cars but hey its an easy set of gauges for whatever
A fillet gauge from 1mm to 20mm with a simple but effective design
Gauge 1 MFA wagon. Scaled up from a OO model. It was printed on a Creality K1C which has a bed 220mm x 220mm. With the size of bed the top box had to be printed in two halves. For the convenience of speed and to reduce the amount of…
this is a 3d model of the narrow gauge train called aagje in my favourite theme park the efteling, i hope you enjoy it!
I was struggling with bed leveling until I got this feeler gauge. So I wanted a holder to keep it close and don't lose it and made this. I hope this helps anyone :)
Advantages: ✔ convenient shell organization ✔ fewer mistakes during reloading ✔ speeds up the reloading process ✔ durable and long-lasting ✔ suitable for 12 and 16 gauge How they are used: 🔹 1 tray — for small batches 🔹 2 trays —…
Hey, this is a Depth Caliper which is useful to measure the depth. To be clear right from the start, you shouldn't expect the highest precision from a 3D-printed caliper. You can measure well with it, and I would say the measurement…
Shotshell box holder for 20 gauge shells. Paint on supports for belt clip, no other supports needed. Second design made for this belt adapter https://www.thingiverse.com/thing:1494715 Please like and give feedback.
I designed electrical outlet stand-off spacers for securing outlets to the electrical box while keeping the outlet flush with the exterior wall surface; that model is here: However, when installing and sizing these spacers, it was kind of…
Remix of Pre-existing Model to Suit my needs Numerous changes to increase part strength, and improve bowden / Original CR10 Heat-sync usage Note: Metal Bowden clip Snug to improve Rigidity, Leave first screw loose when inserting second…
These are resizable plugs designed to hold your miscellaneous goodies. these gauges can be resized to 1.5" when printed at .1mm Layer height. Resize gauge to desired size in slicer Clone Gauge to create a pair Split Gauges to objects then…
Print one of each model and print them in the same orientation with 0.2mm layer hight. I was able to press the front and back cover together, but you might need a bit of glue.
This is a protective sleeve for a pressure gauge of a pressure washer. P/N of the gauge is NILFISK 301000246 - 300bar, 1/8" BSP (28 tpi) thread, OD roughly 41mm, length 26,5mm. Printed out of TPU, 3 outside layers, 25% infill.
Feel free to comment if the design needs updates. I will test with a project and update if changes are required.
Update: Due to the interest in this model I made some aesthetic updates (to make it more readable) in addition to shaving off 0.15mm of thickness (which puts the gauge nearer to the center when the belts are adjusted properly). If you are…
This 1"x1" square metal tube with 1/12" wall end cap can be used to make 1" by 1" square tube safer and also make it so it won't scratch things.
So I made the original just as a replacement. This integrates 52mm gauges similar to the Monaro's optional gauge pod, and the wonderful aftermarket ones that are admittedly a little pricey. Print with something UV and heat resistant. Also…
Tunnel for gauged ears 40 mm but can be resized in slicer to desired MM
It holds the feeler gauges, it's pretty self explanatory. Two slots for metric and SAE. The models I designed around are below: GearWrench 161D Wright 9529 STEP, 3MF, and 3DXML file for SOLIDWORKS xDesign/3DEXPERIENCE CATIA are provided.
The tips are center pins 1,3mm For variable version : threaded insert M3x3 mm and screw M3x5 mm
20% lighter 100rnd case gauge pitched for P-100-9 case-gard.
This is a recreation I did in CAD for a standard skeet 12ga shotgun sub-gauge tube knockout tool. Barrel inserts are full length tubes that convert a 12ga shotgun into either a 20ga, 28ga, or 410ga shotgun for the purposes of competition…
Works for the following tool: https://amzn.to/41PpSUY
In the 50's the Deutsche Bundesbahn started opperating the ETA150 battery powered railcars. https://nl.wikipedia.org/wiki/Baureihe_515 My goal is to my design 3D-print models of typical Dutch rolling stock. This German railcar does…
Same as this paid tool: https://www.ebike24.com/enviolo-shift-cable-gauge Painted 3MF file included for Bambu Studio Used on a Tern GSD
Additional components required 4 x nut M3 3 x countersunk screw M3 x 20 mm 1 x socket head screw M3 × 16 mm Aluminum square tube 15 × 15 × 650 mm (glued into the knob_M3 using 2K epoxy or similar adhesive) Print settings (no special…
AMC Eagle Gauge Panel – Aftermarket Conversion This is a custom gauge panel designed for the optional gauge cluster in the AMC Eagle. My Eagle came with the factory gauge console, but not the proprietary cable needed to connect all the…
This is a custom-designed, 3D printable vent gauge holder specifically made for the BMW E46 platform (1998–2006). Designed to fit directly into the center air vent, this holder allows you to mount a standard 52mm gauge (boost, AFR, oil…
For 3,5 turns of string The length of the gauge needs to be adjusted according to the diameter of the tuning pin. 7mm - 72.5mm 7.10mm - 73.5mm 7.20mm - 74.6mm...etc.
First atemp at designing a model. Printed fine at 0.12mm with matte gray PLA
This piece of track has a center line radius of 248 studs and an arc of 5.625°. A radius of 248 studs was chosen because it is close to the radius of the “Long Smooth Curves” technique created by Holger Matthes…
This model is a multi piece mount designed to hold the DXL360S Dual Axis Level Box and then clip it into the center cap hole on your wheel for taking camber measurements. It's designed in three parts: Main body to hold the Level Box…
Kobalt Digital Tire pressure Gauge Battery cover
This is a measuring tool for easily determining the Z-axis offset. I wanted to level the print bed of my Core ONE and print the following model: However, it is not easy to measure the distance with a caliper, so I printed this model to…
Disclaimer: If you print this a fdm 3D printer (which you probably will) it might not be so accurate, especially for the smaller semi circles. Also, I don't recommend printing this with a material that has a lot of thermal expansion (such…
The Bush Mill Railway had a rake five 16 seat semi open coaches. They ran on the railway from it's opening in March 1986 until it closed on the 30th of June 2004. The coaches went unsold for two years until being purchased alongside…
I upgraded the boxes for these Radius Gauges because I wanted high contrast multi color print on the lids. I also revised the base because I found it difficult to open. So, I lengthened the base and gave a small lip for better leverage.
I loved MIGo’s excellent radius gauge set (1–40mm, inner and outer), but it lacked a Gridfinity-compatible storage option—so I designed one! This remix features a custom Gridfinity box that holds the full gauge set and retains the…
Gauge of my Amica gas stove. Tight fit for 6mm variant (6.2mm inner hole)
Steering column mount this steering column: https://www.speedwaymotors.com/Steering-Column-Mounting-Bracket-3-4-Inch-Shaft-1-25-1-75-Inch,461403.html This is made for the nexgenefi display but if you have basic cad skills this could be…
Fully printable tool for measuring an exact template of a stair tread or riser, that you can then transfer to a workpiece to be cut out. Key features: Fully modular - print as many rails, bolts, knobs, etc. as you need for your situation…
Ring to replace a missing gauge cover. This one is for a 55mm lens up to 1/8" thick. I intended to use some plexiglass, but I cut my ring from a have clear plastic bottle. You cannot tap on it like plexiglass, but it works. This lens…
I've made this enclosure for a Suzuki Tachometer, however it should work with any 85mm gauge. I have a round and a square model (I like better the square). Both models are secured using 8 × M4 screws . The enclosure provides an internal…
Designed for tpu filament. In the images Sunlu tpu 95A translucent orange was used. A few settings that seem to work for me on the core one with sunlu tpu. Layer hight 0.2mm Perimeters around 50mm/s Infill 10% around 65 to 70mm/s Bed…
Built this as a fun challenge. Indexes off cutting edge, bar side, and adjacent tooth. Magnifies height of raker by about 14X. Indicator can be centered by screw adjustment. Metal at all potential wear points. Uses a drill bit for contact…
orchid is another member of the "flower" family of locomotives, based loosely on the Kirklees Light Railway's Fox.
This is a remix of my earlier version of this snow gauge. I increased the area of the base for better stability. This version includes pockets for 2 10x2mm magnets, one on each side of the base. I paused the print before the cavities were…
Ruler Marking Gauge (Boltless Design) Here is a unique, fully 3D-printable marking gauge that clamps directly onto a standard ruler! This is a simple solution that requires zero additional bolts or nuts — just print the parts, assemble…
print with supports and standing on one edge to get most strength and flexibility for the tabs. this replaces the original switch frame for the aux heater switch left of steering wheel. (in LHD cars) model needs further improvement as it…
I was unable to find a (re)railer of longer size for my G-Scale trains that I liked. This is a rescaled H0 railer that I shortened and cut to be able to print in only two pieces using the PrusaSlicer cut tool. I've uploaded the whole…
Inspired by the "Caliper Radius Gauge" from DrTob, I designed my version to work with my TESA mechanical caliper. To ensure that the caliper gauge is held securely in place, I have added a round magnet (diameter 10 mm x 3 mm). And it has…
I highly recommend printing in PETG CF at bare minimum, supports are not needed as the model can be laid on the flat face. Prints in roughly an hour. Feel free to suggest fixes or address possible fitment issues!
Very simple holder/hanger for Limit Marking Gauge ( MGB 200 or MGB 300 ). Use with 4mm screws.
These are Prusa themed ear plugs that I designed in Tinkercad. Scale to fit, but sized @ a 1". My very first design on my first printer!! A Prusa Core 1+
A dedicated wall, desk, or workbench mount for the Park Tool WAG-5 Wheel Alignment Gauge. Keep your workshop organized and your precision tools safe. Print Settings (Tested on Creality Ender 3 v3 KE): Filament: Sunlu PLA+ Infill: 20%…
This is a simple holder for my iGaging Electronic Thickness Gauge. It holds the gauge and the 5 other tips for the gauge. This model mounts to a Dowel rod with a diameter of 1-3/8" or 35mm. STEP file included if you want to change how its…
Tool to measure 12 gauge choke size(Cylinder, Improved Cylinder, Modified, Full) Works for all 12 gauge shotguns. Doesn't need much structural integrity. I did 2 wall loops and 15% infill and works great.
🚆 Streamlined Passenger Car Set – Union Pacific This streamlined passenger car set is the perfect match for the 3D printed EMD F7 locomotive . It features the classic Union Pacific heritage paint scheme , making it an ideal addition to…
Bought a gauge for tramming my printbed on the P2S. Unfortunatly my gauge came with a holder on the backside so i won't fit into the printed toolhead holder for the P2S. This is a replacement cover. I printed it in black PLA.
This is a tool I put together to compare wheel offsets for my 1/10 RC drift car. Operation is simple - fully insert the tool into the 12mm wheel hex and press the slider against the back edge of the wheel. The line that the top edge of…
It's a precision tool for RC enthusiasts designed to safely and easily leverage the built-in smartphone levels for accurate control-surface setup on remote control planes and other RC models available in three versions version 1 (Large…
🇩🇪 Beschreibung Ich hatte immer Probleme die Bremsklötze von Magura Felgenbremsen in allen Dimensionen korrekt auszurichten (vermutlich eine Frage der Übung …) Mit dieser Lehre ist die Montage ziemlich einfach: Die beiden Schablonen…
Inspired by HD-creator's excellent snow gauge for those of us still using imperialist units. I printed in PETG. Next day note - The gauge blew over so I poured some water on the walkway, put the gauge on the water, and put a brick over…
Radius gauge with multi-material or multi-colour markings for convenience. For MMU/AMS users, use the Multi-Material file. For single filament printers, use the Multi-Colour file and add a Color Change . Markings start between the heights…
A little bracket to be attached to the side of a Makita DMP180 Cordless Inflator tool. I wanted to have quick access to a tire pressure gauge and on the side of the inflator tool I would use to inflate said tires would be the best place…
This dual set of 3D-printed radius gauges includes one for outer and one for inner radius, each covering sizes from 10 to 40 mm in 5 mm increments. Designed with minimal material usage, both tools are lightweight, easy to handle, and…
Same as my previous remix but with the addition of a 1.28" round gauge mount. Now you can design gauges anywhere!
O Gauge 2-Bay Hopper Car – 3D Printable This model is a fully 3D printable 2-bay hopper car designed for O Gauge model railroading . It is ideal for transporting coal or other bulk goods on your layout. Almost all parts of the car are 3D…
About this model This gauge allows you to gauge radii and mark a radius precicely on a sharp corner. It also can act as a visual aid on how a rounded corner will look like after routing or sanding. There are several radius gauges out…
Designed to be 27mm these plugs can be scaled to fit your size. Not recommended for sizes smaller than 1/2"
I was looking into going clamming and could not find a gauge, so I had ChatGTP throw this together for me.
Gridfinity bin holder for the Druck 705e pressure gauge DPI705E | Handheld Pressure Indicator | Druck a Baker Hughes business
Gridfinity bin to hold the old style Druck 705 pressure gauge
A 3d printable marking gauge that uses a Veritas wheel gauge blade ~$6CAD. here is a link to the blade I used:…
Information It seems when you order 8 mm magnets of specific sizes, they sometimes are not completely in spec. In most cases the magnets are usually slightly less in all dimensions than their advertised sizes. That's why I developed this…
Gridfinity bin for LIMIT 11911-0104 indicator. With stacking lip and magnet sockets. STEP file included. Printed from eSun's PLA+ Bone White. Made using Lev Mishin's GridfinityGenerator plugin .
This model is for testing 3D printed holes to help you design better tolerances of holes printed perpendicular to the layer lines. The hole diameters are in 1-10 mm range with 0.1 mm increments. The top edges of holes are chamfered.
A simple stand I created for 3 dials controlled by ESPHome. Held together by M4x8mm countersunk screws, prints without any supports (the front plate flush on the bed)
This is a simple 2x2 Gridfinity Bin for the Radius Gauge made by Michal Blazek . Support me by using my referral code on Prusa Website: @maxcou_485438
The standard tip was too far of the nail entry point in my opinion. I also wanted to use nailer with 6 mm plywood (from the edge). And also nail at an angle. Printed in Colorfabb foaming TPU at 200°C and 1.1 flow.
This is a 12 Gauge Shell holder for the MTM Ammo cans: https://www.amazon.com/dp/B01MU6ZAPG Instead of a pile of rounds, you can fit some of these shell holders, each holding 28 shells. Keeps em all tight and easy to pull out a batch...…
This is a Gridfinity bin for a TESA DIGICO 10. Also there is a space for CR2032 Batteries. The Bin is 4x2. There is a space for 6x2 Magnets in the corners. Base generated using Gridfinity bin generator. Custom tool cutout designed from…
Gauge pod for Fiat Linea / Grande Punto. For the driver's side air vent. The pod diameter is 52mm. I added the SCAD file so you can edit it if you want. I added the T-Jet text in the bottom corner, but it is not in the files. Have fun!
